CENTURION SYSTEMS VERT-X Mechanical Installation Manual page 16

1
2
3
4
FIGURE 3. V-SERIES WALL BOX INCLUDING CHARGER AND CONTROLLER
1. 12V 7.2Ah Battery1
2. V-Series Controller with Built-in
Receiver
3. V-Series User Guide
4. V-Series Electrical Setup
Commissioning Guide
1. Batteries can be of a larger capacity for longer power failure autonomy and are not included in the kit. Consult your
local authorised dealer for assistance
5. CP84SM Battery Charger
6. Isolator
7. Code-hopping Remote Controls
page 16
5
6
7
