3.2. Technical Specifications - V400/V500
Input voltage
Motor voltage
Motor power supply
Battery charger
2
Current consumption (Mains)
Current consumption (motor at rated load)
Operator push force - maximum
Operator stroke
Piston extension/retraction speed
Typical gate opening time
Manual override
Maximum number of operations per day
Duty cycle - Mains present
Operations in standby with 7Ah battery
Half day
Full day
Collision Sensing
Operating temperature range
Mass of unit packed (excluding battery)
Single kit
8
Double kit
9
1. Can increase battery capacity for longer standby times
2. Can operate off a solar supply, consult your reseller for assistance
3. Assumes a full stroke of operator is used
4. Each operator comes with a unique set of keys
5. Based on 25°C ambient temperature and unit not in direct sunlight
6. Based on an operator push force of less than 50% of rated
7. Based on double kit excluding Infrared Safety Beams
8. Single kit contains one operator and Wall Box
9. Double kit contains two operators and one Wall Box
www.CentSys.com
3
5 6
7
page 11
V400
90V - 240V AC ± 10%, 50/60Hz
12V DC
Battery-driven (standard capacity - 7Ah)
1.8A @ 13.8V
170mA
15A - maximum
250kgf
400mm
28mm/sec (variable)
14.3 sec
Key release
250
50%
70
58
Electronic
-15°C to +50°C
8.5kg
14kg
V500
1
500mm
17.8 sec
4
9kg
15kg
TABLE 1
