Status display of the device
Status displays for the CGLine+ Web Controller
Operation Red = when at least one luminaire is not operationally ready, e.g. blocked
FT
Yellow = when at least one luminaire is currently undergoing a function test (lumi
OT Yellow = when at least one luminaire is currently undergoing an operating
Blocked Red = when at least one luminaire is currently blocked
Ethernet
Red = when communication between the Controller and CGVision has been dis
Malfunction Red = when at least one luminaire has a malfunction, e.g. battery fault
Ext. monitor Red = malfunction with externally connected device
Admin logged in Green = signals that someone is logged in as administrator on the web server for
Output 1/2
Red = relay outputs in accordance with active configuration
Input 1/2 Yellow = digital inputs in accordance with active configuration
Device window – CGLine+ Web-Controller
naire test)
time test (battery test)
rupted
CGLine+ Web-Controller
