Swap luminaires within a zone
Zone 1 is marked in both windows (1).
Mark the luminaire to be shifted in the right window (2).
Select the luminaire to be replaced in the left window (3).
Tap on the <Swap> button (4).
1
3
The luminaires with address 2 and 5 were swapped in the example.
Luminaire configuration in the strand
