- Page 1 CGLine+ Web Controller Installation and Operating Instructions CGLine+ Web-Controller Target group: Electrical specialists...
-
Page 2: Table Of Contents
7.24 Overview all Web-Controller ..................27 Installation and Operating Instructions CGLine+ Web-Controller 40071860236 (E) February 2019 www.eaton.com... -
Page 3: Introduction / Foreword
USB stick: For convenient logbook CGVision software: Configuration Network PC or CGLine+ Wireless analysis at the PC and full visualisation of 32 x 800 Monitoring Set (optional): Access to Installation and Operating Instructions CGLine+ Web-Controller 40071860236 (E) February 2019 www.eaton.com... -
Page 4: Safety Notes
(e.g., minimum 10 characters, mix of upper- and lower-case and special characters, and expire every 90 days, or otherwise in accordance with your organi- zation’s policies). Restrict Network Access: Ideally, CGLine+ Web-Controller Installation and Operating Instructions CGLine+ Web-Controller 40071860236 (E) February 2019 www.eaton.com... -
Page 5: Technical Data
Flash yellow and green during data transmission. Solid green when connected but no traffic in progress. LED display on the LAN (ethernet connection): Green = flashes with traffic Yellow = link or network connection Installation and Operating Instructions CGLine+ Web-Controller 40071860236 (E) February 2019 www.eaton.com... -
Page 6: Push Button Functions
S1/S2 = Block input USB2 device for connection to PC In1, In2 = 2 x digital inputs PE/N/L 230V 50/60Hz 11, 12, 14, 21, 22, 24 = 2 x relay outputs Installation and Operating Instructions CGLine+ Web-Controller 40071860236 (E) February 2019 www.eaton.com... -
Page 7: Connections
With closer contact Polarity D1/D2 to the luminaires must not be observed. Cable routing for CGLine bus: 2-core bus line, unshielded, free bus CGLine topology possible. Interface With opener contact Installation and Operating Instructions CGLine+ Web-Controller 40071860236 (E) February 2019 www.eaton.com... -
Page 8: First Commissioning And Modifying
USB connections: To modify the network settings of the PC open the system control The CGLine+ Web-Controller has 2 USB connections: 1 x USB A Network and release centre host and 1 x USB B device. USB1 (Type A host):... - Page 9 192.168.1.50. Subnet mask: 255.255.255.0. Clicking on OK assumes the settings so that the web page of the CGLine+ Web-Controller can now be opened via any web browser, e.g. Firefox. Installation and Operating Instructions CGLine+ Web-Controller 40071860236 (E) February 2019 www.eaton.com...
-
Page 10: First Access To The Cgline+ Webserver
Before accessing the web server, two security pages are displayed on the browser by security protocols. The following web pages appear: Click on Continue to this website on the first page. Click on Advanced on the second page, and then on Add Exception. Installation and Operating Instructions CGLine+ Web-Controller 40071860236 (E) February 2019 www.eaton.com... -
Page 11: Login To The Cgline+ Webserver
6 First commissioning and modifying network settings 6 .4 Login to the CGLine+ webserver To setup the networks settings to the IT pretendings, it is necessary to log in as „Admin“ with factory default password “EATON”, The submenus appear. In the submenu „configuration”... -
Page 12: Modifying Of The Network Settings
The CGLine+ Web-Controller can now be integrated in the customer’s intranet. The access from any PC work- station in the intranet via a standard webbrowser is pos- sible now. Installation and Operating Instructions CGLine+ Web-Controller 40071860236 (E) February 2019 www.eaton.com... -
Page 13: Common Operation Of The Web Screens
Password: GUEST The Admin-Account allows full access to the CGLine+ Web-Controller, e.g. start function test. The User account allows only access for monitoring the status of the controller and connected luminaires. It is recommended to change the passwords for security reasons. -
Page 14: Start Screen After Registration
Logbook: Displays the last 100 events of the inspection book on the SD card Building layouts: Displays luminaires in layouts for each zone Overview all Web-Controllers: Displays further installed CGLine+ Web-Controllers in an over- view Installation and Operating Instructions CGLine+ Web-Controller 40071860236 (E) February 2019 www.eaton.com... -
Page 15: Overview Of All Faulty Luminaires (Complete Overview)
• Battery = battery or charge error • Luminaire position = target designation of • White clock = FT failure luminaire • Blue clock = DT failure • i = luminaire operation mode Installation and Operating Instructions CGLine+ Web-Controller 40071860236 (E) February 2019 www.eaton.com... -
Page 16: Overview Of All Faulty Luminaires For Each Zone
“Overview” menu the “Zone” tab Via the drop down menus the desired line and zone are selected. The luminaire list is updated via „Send“ Installation and Operating Instructions CGLine+ Web-Controller 40071860236 (E) February 2019 www.eaton.com... -
Page 17: Overview Of All Luminaires
200 characters (e.g. destina- tion text) of each luminaire. These text can be edited by: CGLine+ PC software CGVision With click on the text on this screen Import of an text-file (see Installation and Operating Instructions CGLine+ Web-Controller 40071860236 (E) February 2019 www.eaton.com... -
Page 18: Configuration Change Of Luminaires Addresses
2. Click on the line you want to modify and choose the new configurations. 3. Click on Save for taking into account the changes. 4. Click on Save for finalizing the modifications. Installation and Operating Instructions CGLine+ Web-Controller 40071860236 (E) February 2019 www.eaton.com... -
Page 19: Switching Command Screen
Update luminaire status: Actualisiation of the luminaire sta- tus of all luminaires If “All” is selected: Command applies to all luminaires Update luminaire type: Actualisation of luminaire type information Installation and Operating Instructions CGLine+ Web-Controller 40071860236 (E) February 2019 www.eaton.com... -
Page 20: Device Information Screen
If the period of mains failure is greater than 21 days, the com- plete system should be re-commissioned. Especially the date and time must be reconfigured to assure proper sequencing Installation and Operating Instructions CGLine+ Web-Controller 40071860236 (E) February 2019 www.eaton.com... -
Page 21: Digital Input/Output" Configuration Screen
Charging failure: At least 1 luminaire has a battery or charge fault Test failure: At least 1 luminaire has an FT or DT fault, e.g. nominal operating time not reached Installation and Operating Instructions CGLine+ Web-Controller 40071860236 (E) February 2019 www.eaton.com... -
Page 22: General Device Settings
IT-department, factory default is cation no. of the web-controller in a network. 192.168.1.200 Subnet mask: Normally provide by the IT-department, fac- tory default is 255.255.255.0 (Class C) Installation and Operating Instructions CGLine+ Web-Controller 40071860236 (E) February 2019 www.eaton.com... -
Page 23: Configuration Of E-Mail
June 2014. A complete logbook is downloadable via log- book.dat. This file is only usable with the CGLine+ PC-software! (see manual CGLine+ PC-software) Installation and Operating Instructions CGLine+ Web-Controller 40071860236 (E) February 2019 www.eaton.com... -
Page 24: Last Events
External programs are required, which are described in the manual for the building layout programming (available on request). Installation and Operating Instructions CGLine+ Web-Controller 40071860236 (E) February 2019 www.eaton.com... -
Page 25: Building Layout - Add A Layout
= normal operation yellow = FT or DT active red = failure Via menu “Building layouts” it is possible to go back to the building layout menu. Installation and Operating Instructions CGLine+ Web-Controller 40071860236 (E) February 2019 www.eaton.com... -
Page 26: Layout Programming - Searching For A Device
7 .22 Layout programming – deleting a layout In the menu “Delete layout” any graphics cre- ated can be deleted again from the web server. Selected plans are removed again via “Delete layout”. Installation and Operating Instructions CGLine+ Web-Controller 40071860236 (E) February 2019 www.eaton.com... -
Page 27: Multi-Site Configuration
Status display of zones, inputs and outputs of all CGLine+ web controllers installed in the network. CGLine+ web controllers installed in the network Installation and Operating Instructions CGLine+ Web-Controller 40071860236 (E) February 2019 www.eaton.com... - Page 28 Eaton is dedicated to ensuring that reliable, efficient and safe power is available when it’s needed most. With unparalleled knowledge of electrical power management across industries, experts at Eaton deliver customized, integrated solutions to solve our customers’ most critical challenges.
