7 Luminaire configuration in the strand
After searching for luminaires, the luminaires found are displayed sorted with their
Hex addresses in ascending order and addressed using a logical short address
(1-200) in the strand.
These luminaires can now be configured in CGVision, e.g. by modifying the short
address, zone allocation or text assignment.
The luminaires of a strand can be configured in the zone window in the Configuration
menu. Select the required strand to configure, e.g. Strand 1.
Zone 1 is selected now, the zone window is opened with
the luminaires with automatic addressing.
Luminaire configuration is started in the Configuration menu.
Luminaire configuration in the strand
