Structure of device window / zone window / luminaire window assembly
6 Structure of device window / zone window / luminaire win-
dow assembly
GB
Structure of the device window with stand status
The full status of the device and the strand status of a selected strand are dis-
played in the device image.
By clicking on the zone required in the strand the "Zone image" opens up.
18 Manual CGLine+ Touchscreen Controller ZNO2038000 A www.eaton.com
Installed strands are displayed with buttons with
a coloured background.
By clicking on a strand, the status and the zones
installed in the relevant strand are displayed in
the left-hand side.
zone2
zone3
zone4
