User Manual
S S t t e e p p
4. Add device.
5.Perform the service settings.
Note： For devices that support automatic search function (like SUNGROW string
inverters), you can search the devices and allocate the address automatically.

9.7 Monitoring

On the "Monitoring" interface, users can perform the following operations:
View information such as the real-time data of devices (for example, inverter)
•
connected to the Logger3000.
Set parameters of devices managed by the Logger3000, including initial parameters,
•
running parameters, protection parameters, and system parameters.
The left sidebar "Overview" displays a list of devices currently managed by the
Logger3000.

9.7.1 View Real-Time Data

Click "Monitoring" -＞ "Real-time data" to enter the corresponding interface.
Select a device, for example, an inverter, from the sidebar "Overview" to view real-time
data of the corresponding device.
Click "DC data" and "Device attributes" on this interface to view corresponding
information.
Tick the checkbox "Auto refresh" so that the system will refresh data once every 10s.
R R e e f f e e r r e e n n c c e e c c h h a a p p t t e e r r
"9.8.2 Device Operation"
"9.9.5 Modbus Service"
"9.9.6 IEC104 Service Settings"
"9.9.7 IEC104 Main Protocol Settings
(Optional)"
9 Web Interface
37
