9 Web Interface

9.7.2 Single-Parameter Setting

step 1 Select a device from the left sidebar "Overview".
step 2 Tick a to-be-set parameter and enter the setting value.
step 3 Click "Setting."
- - - - E E n n d d

9.7.3 Batch Setting

step 1 Select a device from the left sidebar "Overview".
step 2 Tick multiple to-be-set parameters and enter the setting values.
step 3 Click "Batch setting".
- - - - E E n n d d

9.7.4 Parameter Readback

The function is used to read out set parameter values of the current device.
step 1 Select a to-be-read back device from the left sidebar "Overview".
step 2 Tick a to-be-read back parameter.
step 3 Click "Query" to read out the parameter value of the device.
- - - - E E n n d d
If parameter values fall beyond the set range or the device does not support
the readback function, the set values will be in red.

9.7.5 Checking the Parameter Setting Log

The function is used to view parameter setting logs of a device. The method is as
follows:
step 1 Click the icon
interface.
step 2 Select a device name.
step 3 Click "Search".
- - - - E E n n d d

9.8 Device Management

The "Management" menu is used to manage devices connected to the Logger3000
and configure addresses for them.
38
in the upper right corner on the "Monitoring" -＞ "Param. setting"
