6.3 Installing Logger3000

The Logger3000 can be installed anywhere in the room meeting the installation
environment requirements. Wall-mounted installation and rack-mounted installation are
supported.

6.3.1 Wall-Mounted Installation

Avoid drilling holes in the utility pipes and/or cables attached to back of the wall!
Turn on the vacuum cleaner and wear safety goggles and dust mask
throughout the drilling process to avoid dust inhalation or contact with eyes.
Installation component parts
Marker (beyond the delivery scope)
•
Hammer drill (beyond the delivery scope)
•
Bottom supporter (in the delivery scope)
•
Mounting ear (in the delivery scope)
•
6 Mechanical Installation
17
