9

Web Interface

9.1 Running Requirements

I I t t e e m m
System
Browser
Min. resolution
CPU

9.2 Preparation before Login

Connect the PC to the ETH2 port of the Logger3000, and the IP address of the ETH
•
port is 192.168.1.100 by default.
Set the PC IP address to a value within the same network segment as that of the IP
•
address of the port ETH2. For example, the PC IP address can be set to
192.168.1.125 and the subnet mask to 255.255.255.0.

9.3 Login Steps

step 1 Enter the IP address, for example, 192.168.1.100, of the port ETH2 in the address bar
of the PC, to enter the login interface, as shown in the figure below.
step 2 Select the desired language and user role (for example, O&M user), enter the default
password "adamg1", fill in the verification code, and click "Login".
R R o o l l e e
O & M user
R & D user
Factory user
Anonymous
34
P P a a r r a a m m e e t t e e r r
WIN7, WIN8, WIN10
IE10 - IE11, Chrome43 - Chrome45
1366 x 768
CPU frequency higher than 2.5GHz
P P a a s s s s w w o o r r d d
adamg1
Unavailable
Unavailable
Log in without a password
