Never modify the device address arbitrarily. Make sure the new address is not
repeated and consistent with the actual device address.

9.8.2 Device Operation

This function is used to add, modify, and delete devices connected to the Logger3000.
A A d d d d D D e e v v i i c c e e
Click "Add device" on the "Device operation" interface, and fill in the required
information on the pop-up window.
P P a a r r a a m m e e t t e e r r
Port
Device type
Device number
D D e e s s c c r r i i p p t t i i o o n n
Includes COM1~COM6, PLC, NET_TCP, and NET_IEC104
Select the corresponding type of the device
The max. value is 5 when the port parameter is set to "NET_
TCP" or "NET_IEC104"
It can only be set to 1 when the port parameter is set to "NET_
IEC104"
9 Web Interface
41
