9 Web Interface

9.9.6 IEC104 Service Settings

This function is used to configure the IEC104 services of the Logger3000. The method
is as follows:
Click "Settings" -＞ "IEC104 service settings" to enter the corresponding interface.
If the access IP is set to "0.0.0.0", any background device with valid IP address
can access the Logger3000.
If the access IP is set to a specific value, only this background can access the
Logger3000.

9.9.7 IEC104 Main Protocol Settings (Optional)

If a device whose type is NET_IEC104 has been added on the "Management" -＞ "-
Device operation" interface, perform this setting accordingly.
P P a a r r a a m m e e t t e e r r
A A d d d d r r e e s s s s d d e e s s c c r r i i p p t t i i o o n n
Public address
46
D D e e s s c c r r i i p p t t i i o o n n
Address of different
slave stations on the
IEC104 link
R R a a n n g g e e
1~255
