5.13 CAN Menu

The parameter in this menu are used only in the ADP200 PID-IMM multi-pump configuration.
The example described in multi pump menu show how program the parameter Slave xActive and master
address.
Ipa Parameter Name
11602 Slave1Active
11604 Slave2Active
11606 Slave3Active
11608 Slave4Active
11610 Slave5Active
11612 Slave6Active
11614 MasterAddress
11616 DivSlaveAddr
11618 RPDOTimer
11620 TPDOTimer
11622 StandAlone
11624 CANAlarm
11626 CANMPActive
11628 PLC Ref Div
11630 MPCopyWDecomp
12054* COState
12056* SlaveState1
12058* SlaveState2
12060* SlaveState3
12062* SlaveState4
12064* SlaveState5
12066* SlaveState6
Slave1Active If on set the presence of the slave 1. From Default configuration only slave 1 is active.
0=OFF
1=ON
Slave2Active If on set the presence of the slave 2. From Default configuration only slave 1 is active.
0=OFF
1=ON
Slave3Active If on set the presence of the slave 3. From Default configuration only slave 1 is active.
0=OFF
1=ON
Slave4Active If on set the presence of the slave 4. From Default configuration only slave 1 is active.
0=OFF
1=ON
Slave5Active If on set the presence of the slave 5. From Default configuration only slave 1 is active.
0=OFF
1=ON
Slave6Active If on set the presence of the slave 1. From Default configuration only slave 1 is active.
0=OFF
1=ON
MasterAddress
Address of the master drive (Default is 3). Must be equal in all the drives.
Parameter variation have effect only after reset.
ADP200 Application PID-IMM
Unit Type
- BOOL
- BOOL
- BOOL
- BOOL
- BOOL
- BOOL
- UINT
- UINT
- INT
- INT
- CO_STAND_ALONE 0
- BOOL
- BOOL
- FLOAT
- BOOL
- UDINT
- BOOL
- BOOL
- BOOL
- BOOL
- BOOL
- BOOL
User Manual
Default Min
ON -
OFF -
OFF -
OFF -
OFF -
OFF -
3 -
6 -
12 -
10 -
-
OFF -
ON -
1 0.1
OFF -
0 -
OFF -
OFF -
OFF -
OFF -
OFF -
OFF -
Max
-
-
-
-
-
-
-
-
-
-
-
-
-
1000
-
-
-
-
-
-
-
-
