Step 10 - Setting PID_IMM application parameters
Enter the nominal speed of the pump, the nominal pressure value, and the full-scale of the pressure sensor.
The application can automatically set the typical configuration with PID-IMM using analog and digital I/Os by
using the IPA 11014 AutoSetup command.
Set Auto Setup -> ON, the application run automatically the setup and at the end bring it to OFF.
The recipe list on the default drive is empty, but is completed with preset parameters at the AutoSetup
command (IPA 11014), which normally must be enabled at this stage of commissioning of the drive.
Paragraph 5.1.1 "List of parameters for CONFIGURATION MENU" shows the preset recipe at the Auto-
Setup command.
