Drive 1 is the master of Drive 2 and Drive 3 are slaves, Drive 4 is Divergent Master while Drive 5 is
Divergent Slave (slave of drive 4)
Also here the master Drive 1 receive the commands (analog and digital input) and read the first pressure
feedback from the first pressure sensor now also Drive 4 is a Master so receive independent commands
from PLC and read a second pressure sensor to perform a second movement.
The machine can perform two movement in parallel (ex. Clamp open and ejector in parallel).
On master drive "DRIVE 1" Tot Number of Pumps [11300]= 5
On slave div. Master "DRIVE 4" Tot Number of Pumps [11300]= 2

5.11.1 MULTIPUMP parameter list

Ipa Parameter Name
11298 Ramp Time
11300 Tot Number of Pumps
11302 Slave Pmp Flow Ratio
11304 Switch Threshold
Ramp Time
Tot Number of Pumps Only for Master or Slave-Div Master specify the total number of pumps that are
Slave Pmp Flow Ratio It is the ratio between the Master displacement and the Slave displacement.
Switch Threshold
ADP200 Application PID-IMM
Unit
-
-
-
perc
Not used
connected. For Slave-Div Master is the total number of pumps considering only
the divergent mode (1 or 2)
It is the Master speed threshold that makes enable the slaves
Type Default
FLOAT 0.2
UINT 1
FLOAT 1
INT 25
User Manual
Min Max
0.00 10.00
1.00 7.00
0.10 10.00
0.00 100.00
