2.5.4 Wiring Examples
2.5.4
Wiring Examples
The following illustrate how to connect single and dual power supplies to the device.
Figure 2.15
Figure 2.16
22
Single High AC/DC Power Supply
Single Low DC Power Supply
RUGGEDCOM RST2228P
Installation Manual, 12/2019, C79000-G8976-1403-05
