Device Management
3.3 Inserting/Removing the CLP
Installing the CLP
To install the CLP, do the following:
1.
2.
28
Remove the protective cover from the CLP port.
1
Protective cover
1
CLP
2
Figure 3.2
Installing the CLP
Insert the CLP into the CLP port.
2
RUGGEDCOM RST2228P
Installation Manual, 12/2019, C79000-G8976-1403-05
