5.3 Failsafe Alarm Relay Specifications
Voltage Range
a
The required wire size depends on the number of POE modules installed in the system and the
maximum current capability of the POE power source. Each POE module will draw up to 3A maximum
with a system maximum of 12A. Follow applicable local wiring codes and standards for minimum wire
gage.
5.3

Failsafe Alarm Relay Specifications

Maximum Switching Voltage
5.4

Supported Networking Standards

5.5

Operating Environment

The RUGGEDCOM RST2228P is rated to operate under the following environmental
conditions.
36
Power In
Internal
Fuse Rating
45-57 VDC
30 VDC
125 VDC
150 VAC
Parameter 10 Mbps
IEEE 802.1AB
ü
IEEE 802.1D
ü
IEEE 802.1Q
ü
IEEE 802.1p
ü
IEEE 802.1x
ü
IEEE 802.3
ü
IEEE 802.3u
IEEE 802.3z
IEEE 802.3ab
IEEE 802.3ae
IEEE 802.3af
ü
IEEE 802.3at
ü
IEEE 802.3x
ü
Power Out
44-57 VDC, 15 W per Port
Maximum (IEEE 302.af)
Rated Switching Current
2 A
0.15 A
2 A
100 1000 10000
Mbps Mbps Mbps
ü ü ü
ü ü ü
ü ü ü
ü ü ü
ü ü ü
ü
ü
ü
ü
ü ü
ü ü
ü ü ü
Wire Gage
Isolation
1.5kVAC
1.5kVAC
1.5kVAC
Notes
Link Layer Discov-
ery Protocol (LLDP)
MAC bridges
VLAN (Virtual LAN)
Priority levels
Port-based net-
work access control
10Base-T
100Base-TX/100Base-FX
1000Base-SX/LX
1000Base-TX
10GBase
Power over Ethernet ports
PoE+ ports, 4-pair
Full duplex operation
RUGGEDCOM RST2228P
Installation Manual, 12/2019, C79000-G8976-1403-05
