Communication Ports
4.1 SFP Transceivers
Note
When more than two 40km or 80km SFP+ tranceivers are installed, the maximum
temperature at which the device can operate will be reduced to 75 °C (165°F).
LEDs
Each socket features an LED that indicates its link state.
Green (Solid)
Green (Blinking)
Off
Compatible SFP Transceivers
The following SFP transceivers are compatible with the RUGGEDCOM RST2228P. For
more information, including installation/removal instructions and ordering infor-
mation, refer to the
try.siemens.com/cs/ca/en/view/109482309]
NOTICE
Only use SFP transceivers approved by Siemens for RUGGEDCOM products. Siemens
accepts no liability as a result of performance issues related in whole or in part to
third-party components.
SFP Transceiver
RUGGEDCOM SFP1112-1
RUGGEDCOM SFP1121-1FX2A
RUGGEDCOM SFP1121-1FX2
RUGGEDCOM SFP1131-1FX20
RUGGEDCOM SFP1131-1FX50
RUGGEDCOM SFP1131-1FX90
RUGGEDCOM SFP1122-1SX
RUGGEDCOM SFP1122-1SX2
RUGGEDCOM SFP1132-1LX10
RUGGEDCOM SFP1132-1LX25
RUGGEDCOM SFP1132-1LX40
RUGGEDCOM SFP1132-1LX70
RUGGEDCOM SFP1132-1LX100
RUGGEDCOM SFP1132-1LX115
RUGGEDCOM SFP2133-1LR10
RUGGEDCOM SFP2133-1ER40
RUGGEDCOM SFP2133-1ZR80
a
MM = Multi-Mode, SM = Single-Mode
30
State
RUGGEDCOM SFP Transceiver Catalog [https://support.indus-
Order Code
6GK6000-8CG01-0AA0
b
6GK6000-8FE50-0AA0
c
6GK6000-8FE51-0AA0
c
6GK6000-8FE52-0AA0
c
6GK6000-8FE53-0AA0
c
6GK6000-8FE54-0AA0
6GK6000-8FG51-0AA0
6GK6000-8FE58-0AA0
6GK6000-8FG52-0AA0
6GK6000-8FG53-0AA0
6GK6000-8FG57-0AA0
6GK6000-8FG54-0AA0
6GK6000-8FG55-0AA0
6GK6000-8FE56-0AA0
b
6GK6000-8FT51-0AA0
b
6GK6000-8FT53-0AA0
b
6GK6000-8FT52-0AA0
Description
Link established
Activity
No link detected
.
a
Speed Mode
(Mbit/s)
10/100/1000 —
100 MM
100 MM
100 SM
100 SM
100 SM
1000 MM
1000 MM
1000 SM
1000 SM
1000 SM
1000 SM
1000 SM
1000 SM
10000 SM
10000 SM
10000 SM
Installation Manual, 12/2019, C79000-G8976-1403-05
Nominal Distance (km)
0.1
2
2
20
50
90
0.5
2
10
25
40
70
100
115
10
40
80
RUGGEDCOM RST2228P
