6.1.8 Other Approvals
6.1.8

Other Approvals

This device meets the requirements of the following additional standards:
•
•
•
•
•
6.2

EMC and Environmental Type Tests

The RUGGEDCOM RST2228P has passed the following EMC and environmental tests.
EMC Type Test for IEC 61850-3
Note
•
•
•
IEC 61000-4-2
IEC 61000-4-3
IEC 61000-4-4
44
IEC 61850-3
General Requirements
EN 50121-4
Railway Applications – Electromagnetic Compatibility – Emission and Immunity
of the Signaling and Telecommunications Apparatus
EN 50121-3-2
Railway applications – Electromagnetic compatibility – Part 3-2: Rolling stock –
Apparatus
EN 50155
Railway applications – Rolling stock – Electronic equipment
NEMA TS-2
Traffic Controller Assemblies with NTCIP Requirements
In the case of an all fiber port configuration, this product meets all Class 2 re-
quirements. Otherwise, all Class 1 requirements are met for copper ports.
If the unit contains copper ports, the IEC 1613 conformance is Class 1, during
which disturbance errors may occur but recovery is automatic.
If the unit contains all fiber ports, the IEC1613 conformance is Class 2, during
which no disturbance errors will occur.
Test
ESD
Radiated RFI
Burst (Fast
Transient)
Description
Enclosure Contact
Enclosure Air
Enclosure Ports
Signal Ports
DC Power Ports
AC Power Ports
Earth Ground Ports
Test Levels Severity Levels
± 8 kV
± 15 kV
20 V/m Note
± 4 kV at 2.5 Note
and 5 kHz
± 4 kV at 2.5
and 5 kHz
± 4 kV at 2.5
and 5 kHz
± 4 kV at 5 kHz
RUGGEDCOM RST2228P
Installation Manual, 12/2019, C79000-G8976-1403-05
4
4
a
a
4
4
4
