Technical Specifications

This section provides important technical specifications related to the device.
5.1

Power Supply Specifications

Note
When determining cable lengths, make sure the minimum input voltage for the pow-
er supply is provided at the power source.
Note
Use the internal fuse rating to determine the size of the external circuit breaker/fuse.
Power Sup-
12 VDC (Single)
24 VDC (Single)
48 VDC (Single)
High Volt-
age AC/DC
a
Based on nominal input voltages and 60W output load.
b
Rated at frequency range 47Hz - 63Hz.
5.2

PoE Power Supply Specifications

The RUGGEDCOM RST2228P adheres to the following power output and IEEE specifi-
cations depending on the input voltage supplied to the device.
Electrical hazard — risk of damage to the device. Do not connect or disconnect the
POE power terminal block when the POE power source is on.
Voltage Range
RUGGEDCOM RST2228P
Installation Manual, 12/2019, C79000-G8976-1403-05
Input Range
ply Type
Min
10.5 VDC
13 VDC
36 VDC
88 VDC
b
85 VAC
CAUTION
Power In
Internal
Fuse Rating
51-57 VDC 12 A Maximum
Internal
Fuse Rating
Max
15 VDC 12 A
36 VDC 10 A
72 VDC 5 A
300 VDC 3.15 A
b
264 VAC
Power Out
50-57 VDC, 60 W per Port
Maximum (IEEE 302.at)
5
Maximum Wire Gage
Power Con-
a
sumption
77 W #14 AWG
72 W #14 AWG
72 W #16 AWG
77 W/ 76W #16 AWG
75 W/ 75W
Wire Gage
#18-#12 AWG
a
