TP48200A-DT19C1, TP48200A-DT19C2,
TP48200A-HT19C1 and TP48200A-HT19C2 Telecom
Power
User Manual
Appearance and Pin Definitions
Figure 3-27 Appearance of the current transformer
Figure 3-28 Appearance and pins of the intelligent electric meter
Table 3-12 Pin definitions of the intelligent electric meter
Pin
1,2
3,4
Issue 03 (2019-11-15)
Definitions
Power supply
RS485 communication
