TP48200A-DT19C1, TP48200A-DT19C2,
TP48200A-HT19C1 and TP48200A-HT19C2 Telecom
Power
User Manual
Item
Installation mode
Maintenance mode
Cable routing
A.5 HXC70S Heat Exchanger Specifications
Table A-5 HXC70S heat exchanger specifications
Item
Maximum power consumption
Typical power consumption
Heat exchanging capacity
Input voltage
Service life
Operating temperature
Storage temperature
Alarm reporting
Altitude
Failure rate
Relative humidity
Noise
A.6 Direct Ventilation Specifications
Table A-6 Direct ventilation specifications
Item
Maximum power consumption
Typical power consumption
Heat exchanging capacity
Issue 03 (2019-11-15)
Specifications
 Battery compartment: IP55
Can be installed on a floor, rooftop, and wall, but cannot be stacked
or installed along a pole.
Operated and maintained from the front
Routed in and out from the bottom
Specifications
68 W
50 W
800 W (80 W/K, +10° C)
-48 V DC
10 years
-40° C to +45° C
-40° C to +70° C
Generates alarms over dry contacts. Normal: closed;
faulty: open
< 4000 m
< 1%
5%-100% (RH)
< 65 dB (A)
Specifications
68 W
50 W
2000 W (120 W/K, +10° C)
Copyright © Huawei Technologies Co., Ltd.
A Technical Specifications
97
