TP48200A-DT19C1, TP48200A-DT19C2,
TP48200A-HT19C1 and TP48200A-HT19C2 Telecom
Power
User Manual
Table 2-1 Configurations
Item
Application
environment
Temperature
control unit (TCU)
Space for customer
equipment
AC input system
AC input circuit
breaker
(Optional) AC
output circuit
breaker
DC output
Rectifier
SMU
UIM
Sensor
(Optional)
Intelligent electric
meter
(Optional)
Bluetooth door lock
Battery
Issue 03 (2019-11-15)
TP48200A-DT19C TP48200A-DT19C
1 2
Class B

Equipment compartment: direct
ventilation

Battery compartment: thermoelectric
cooler (TEC)
14 U
220/380 V AC 110 V AC dual-live
three-phase, wire
four-wire input
system, compatible
with 220 V AC
single-phase input
system
One 3-pole 63 A One 2-pole 100 A
circuit breaker circuit breaker
One 2-pole 10 A circuit breaker and one 3-pole maintenance socket protected by an 10 A
electric residual current device (RCD).
 Battery low voltage disconnection (BLVD): two 1-pole 10 A circuit breakers and
four 1-pole 16 A circuit breakers
 Load low voltage disconnection (LLVD): one 1-pole 100 A circuit breaker, one
1-pole 63 A circuit breaker, and four 1-pole 32 A circuit breakers

Battery route: two 1-pole 125 A circuit breakers
A maximum of four R4850G2s or R4830G2s can be configured.
One SMU02B
One UIM02C
 Mandatory: one battery temperature sensor, one ambient temperature sensor in the
equipment compartment, and one door status sensor
 Optional: one smoke sensor, one ambient temperature and humidity sensor, and one
water sensor.
One intelligent electric meter and one current transformer
One electric door lock and one Bluetooth controller
The battery compartment with two layers supports a maximum of two 12 V, 180 Ah
battery strings.
Copyright © Huawei Technologies Co., Ltd.
TP48200A-HT19C TP48200A-HT19C
1 2
Class C

Equipment compartment: HXC70S
heat exchanger

Battery compartment: TEC
16U
220/380 V AC 110 V AC dual-live
three-phase, wire
four-wire input
system, compatible
with 220 V AC
single-phase input
system
One 3-pole 63 A One 2-pole 100 A
circuit breaker circuit breaker
