TP48200A-DT19C1, TP48200A-DT19C2,
TP48200A-HT19C1 and TP48200A-HT19C2 Telecom
Power
User Manual
Pin
5
6
7
8
10
3.10 (Optional) Bluetooth Door Lock
The Bluetooth door lock consists of the electric door lock and Bluetooth controller which is
used to control the electric door lock.
3.10.1 (Optional) Electric Door Lock
Appearance
Figure 3-29 shows an electric door lock.
Figure 3-29 Electric door lock
Issue 03 (2019-11-15)
Definitions
Phase A voltage
Phase B voltage
Phase C voltage
Neutral wire
Current transformer port
Copyright © Huawei Technologies Co., Ltd.
3 Components
47
