- Page 1 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 V100R005 Installation Guide Issue Date 2014-02-23 HUAWEI TECHNOLOGIES CO., LTD.
- Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...
-
Page 3: About This Document
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide About This Document About This Document Purpose This document describes how to install and commission the power system. The cabinet figures in this document are for reference only. Intended Audience This document is intended for: ... - Page 4 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide About This Document Change History Changes between document issues are cumulative. The latest document issue contains all the changes made in earlier issues. Issue 03 (2014-02-23) Optimized the content of the document.
-
Page 5: Table Of Contents
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide Contents Contents About This Document ........................ii 1 Safety ............................... 1 1.1 Health and Safety ................................1 1.1.1 Overview ................................... 1 1.1.2 Electrical Safety ................................. 3 1.1.3 Inflammable Environment ............................4 1.1.4 Battery .................................. - Page 6 7.3 Installing DC Output Power Cables ..........................63 7.4 Installing AC Input Power Cables ..........................64 7.4.1 Installing AC Input Power Cables for the TP48200A-DT19C1 or TP48200A-HT19C1 ......... 65 7.4.2 Installing AC Input Power Cables for the TP48200A-DT19C2 and TP48200A-HT19C2 ........69 8 (Optional) Installing Batteries ....................
- Page 7 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide Contents 10.2 Setting the Display Language ........................... 82 10.3 Setting the Date and Time ............................82 10.4 Setting the AC Input System ............................. 82 10.5 Setting Battery Parameters ............................83 10.6 Setting Sensor Parameters ............................84 10.7 (Optional) Setting Hibernation Parameters .......................
-
Page 8: Safety
When operating Huawei equipment, in addition to following the general precautions in this document, follow the specific safety instructions given by Huawei. Only trained and qualified personnel are allowed to install, operate, and maintain Huawei equipment. This product should be used in the environment that meets design specifications. - Page 9 Only qualified professional personnel are allowed to install, configure, operate, and disassemble the device. Only the personnel authenticated or authorized by Huawei are allowed to replace or change the device of the parts of the device (including the software). Issue 03 (2014-02-23) Huawei Proprietary and Confidential Copyright ©...
-
Page 10: Electrical Safety
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 1 Safety Any fault or error that might cause safety problems must be reported immediately to a supervisor. Only qualified personnel are allowed to remove or disable the safety facilities and to troubleshoot and maintain the device. -
Page 11: Inflammable Environment
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 1 Safety Dedicated tools must be used during high voltage and AC operations. Avoid using ordinary tools. High Electrical Leakage Ground the device before powering it on. Otherwise, personal injury or device damage may be caused by high leakage current. - Page 12 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 1 Safety If the power system is not powered on and does not supply power to any load for more than two weeks, turn off all battery loops. Basic Precautions Before installing and maintaining the battery, note the following: ...
-
Page 13: Working At Heights
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 1 Safety Do not use unsealed lead acid storage batteries. Lead acid storage batteries must be placed horizontally and stably to prevent the batteries from releasing flammable gas, which may cause fire or erode the device. - Page 14 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 1 Safety Prevent the devices and tools that you carry from falling down. Take safety and protection measures, for example, wear a helm and safety belt. Wear warm clothes when working at heights in a cold region.
-
Page 15: Mechanical Safety
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 1 Safety Using Ladders Checking a Ladder Before using a ladder, check whether the ladder is damaged. Only the ladder in good condition can be used. Before using a ladder, you should know the maximum weight capacity of the ladder. -
Page 16: Bundling Signal Cables
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 1 Safety Sharp Objects Before you hold or carry a device, wear protective gloves to avoid getting injured by sharp edges of the device. Handling Fans When handling fans, note the following: ... -
Page 17: Electrostatic Discharge
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 1 Safety If the "high electrical leakage" tag is present on the power terminal of the device, you must ground the device before powering it on. 1.2.2 Electrostatic Discharge The static electricity generated by human bodies may damage the electrostatic-sensitive components on boards, for example, the large-scale integrated (LSI) circuits. -
Page 18: Installation Preparations
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 2 Installation Preparations Installation Preparations 2.1 Required Tools Figure 2-1 lists the tools that are required for the installation. Use tools with insulated handles. Issue 03 (2014-02-23) Huawei Proprietary and Confidential... -
Page 19: Technical Specifications
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 2 Installation Preparations Figure 2-1 Installation tools 2.2 Technical Specifications Table 2-1 Technical specifications Model Dimensions (H x W x D) Weight Cabinet TP48200A- 2030 mm x 820 mm x 760 mm <... -
Page 20: Installation Dimensions
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 2 Installation Preparations Model Dimensions (H x W x D) Weight ≤ 2 kg Rectifier R4850G2 40.8 mm x 105 mm x 281 mm ≤ 1.8 kg R4830G2 2.3 Installation Dimensions Figure 2-2 shows the installation dimensions. - Page 21 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 2 Installation Preparations Power cables must be routed straightly. No joint or weld can be found in a power cable. In case of insufficient cable length, use a longer cable.
- Page 22 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 2 Installation Preparations Figure 2-4 Distribution of the cable holes on the bottom plate (1) AC cables (reserved) (2) AC input cables (3) DC cables (reserved) Issue 03 (2014-02-23) Huawei Proprietary and Confidential...
-
Page 23: Components
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 3 Components Components 3.1 Interior TP48200A-DT19C1 Figure 3-1 shows the TP48200A-DT19C1 interior. Issue 03 (2014-02-23) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. - Page 24 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 3 Components Figure 3-1 TP48200A-DT19C1 interior (1) (Optional) Intelligent (2) (Optional) (3) Air filter electric meter Maintenance socket (4) (Optional) Electric door (5) (Optional) Bluetooth (6) TCUA control box lock controller...
- Page 25 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 3 Components TP48200A-DT19C2 Figure 3-2 shows the TP48200A-DT19C2 interior. Figure 3-2 TP48200A-DT19C2 interior (1) (Optional) Intelligent (2) (Optional) (3) Air filter electric meter Maintenance socket (4) (Optional) Electric door (5) (Optional) Bluetooth...
- Page 26 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 3 Components (16) Battery switch (17) Cabinet ground bar (18) (Optional) Current transformer TP48200A-HT19C1 Figure 3-3 shows the TP48200A-HT19C1 interior. Figure 3-3 TP48200A-HT19C1 interior (1) (Optional) Intelligent (2) (Optional) (3) Heat exchanger (HXC70S)
- Page 27 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 3 Components (7) TEC (8) Space for installing (9) Space for installing batteries customer equipment (10) Space for installing (11) UIM (12) SMU rectifiers (13) DC PDU (14) AC input circuit...
- Page 28 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 3 Components Figure 3-4 TP48200A-HT19C2 interior (1) (Optional) Intelligent (2) (Optional) (3) Heat exchanger (HXC70S) electric meter Maintenance socket (4) (Optional) Bluetooth (5) (Optional) Electric (6) TCUA control box controller door lock...
-
Page 29: Rectifier
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 3 Components 3.2 Rectifier Rectifiers convert AC input into stable DC output. Figure 3-5 Rectifier (1) Power indicator (2) Alarm indicator (3) Fault indicator (4) Locking latch (5) Handle Table 3-1 Rectifier indicators... -
Page 30: Smu02B
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 3 Components Indicator Color Status Description The rectifier is hibernating. Blinking The communication between the rectifier and at 0.5 Hz the SMU is interrupted. Fault indicator The rectifier is running properly. - Page 31 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 3 Components Figure 3-7 SMU02B panel (1) Run indicator (2) Minor alarm indicator (3) Major alarm indicator (4) Buttons (5) USB port (reserved, the (6) RS485/RS232 port port is protected by a security mechanism.)
- Page 32 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 3 Components Buttons Table 3-3 describes the buttons on the SMU02B panel. Table 3-3 SMU02B button description Button Name Description Turns to the previous menu or sets parameter values. When setting parameter values, you can hold down quickly adjust values.
- Page 33 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 3 Components Figure 3-8 Pins in the FE port and RS485/RS232 port Table 3-5 Pin definitions for the FE port Signal Description Sends data over FE. Receives data over FE. 4, 5, 7, and 8 None N/A.
-
Page 34: Uim02C
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 3 Components 3.4 UIM02C Panel The user interface module (UIM02C) supports eight dry contact outputs, nine dry contact inputs (including six universal dry contact inputs, one smoke sensor input, one water sensor... - Page 35 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 3 Components Port Type Silk Screen Description Dry contact output ALM1 NOTE ports For the associations between the dry contact output ALM2 ports and alarms, see the appendix. ALM3 ALM4 ALM5...
- Page 36 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 3 Components Table 3-9 Pin definitions for the COM port Signal Description Receives data over RS485. Sends data over RS485. PGND Connects to the ground. 3, 7, 8 None Pins Figure 3-11 shows the pin numbers of the sensor ports.
-
Page 37: Sensor
12 V BTEMP BTEMP 3.5 Sensor Figure 3-12 shows the positions of all sensors in the TP48200A-DT19C1 & DT19C2 while Figure 3-13 shows those for the TP48200A-HT19C1 & HT19C2. Issue 03 (2014-02-23) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. - Page 38 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 3 Components Figure 3-12 Sensors (TP48200A-DT19C1 & DT19C2) (1) (Optional) Ambient temperature and (2) Door status sensor (3) (Optional) Smoke humidity sensor sensor (4) Temperature sensor in the equipment (5) Battery temperature...
- Page 39 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 3 Components Figure 3-13 Sensors (TP48200A-HT19C1 & HT19C2) (1) (Optional) Ambient (2) Door status (3) Temperature sensor in the temperature and humidity sensor sensor equipment compartment (4) (Optional) Smoke sensor (5) Battery...
-
Page 40: Optional) Smoke Sensor
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 3 Components 3.5.1 (Optional) Smoke Sensor Figure 3-14 Smoke sensor 1 (1) Wiring port (2) Base (3) Indicator Figure 3-15 Smoke sensor 2 (1) Wiring port (2) Base (3) Indicator Issue 03 (2014-02-23) Huawei Proprietary and Confidential Copyright ©... -
Page 41: Optional) Temperature And Humidity Sensor
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 3 Components 3.5.2 (Optional) Temperature and Humidity Sensor Figure 3-16 Temperature and humidity sensor 1 Figure 3-17 Temperature and humidity sensor 2 Issue 03 (2014-02-23) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. -
Page 42: Optional) Water Sensor
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 3 Components 3.5.3 (Optional) Water Sensor Figure 3-18 Water sensor 3.5.4 Battery Temperature Sensor Figure 3-19 Battery temperature sensor 3.5.5 Temperature Sensor in the Equipment Compartment Figure 3-19 shows the temperature sensor in the equipment compartment. - Page 43 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 3 Components Appearance and Pin Definitions Figure 3-20 Appearance of the current transformer Figure 3-21 Appearance and pins of the intelligent electric meter Table 3-11 Pin definitions of the intelligent electric meter...
-
Page 44: Optional) Bluetooth Door Lock
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 3 Components Definitions Phase B voltage Phase C voltage Neutral wire Current transformer port 3.7 (Optional) Bluetooth Door Lock The Bluetooth door lock consists of the electric door lock and Bluetooth controller which is used to control the electric door lock. -
Page 45: Optional) Bluetooth Controller
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 3 Components Table 3-12 Port definitions of the electric door lock Definitions Description Sends data over RS485. +12 V Supplies power for the electric door lock Receives data over RS485. OPEN_DOOR... -
Page 46: Optional) Battery
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 3 Components Port Definitions Figure 3-25 Ports on the Bluetooth controller Table 3-13 Port definitions of the Bluetooth controller Definitions AC input AC input Connects to pin 4 Connects to pin 3... -
Page 47: Installing Cabinets
Procedure Step 1 Check whether the packing cases are intact. If a packing case is severely damaged or wet, identify the cause and report the issue to your local Huawei office. Step 2 Unpack the cases. Step 3 Check the quantity of components against the packing lists attached to the packing cases. If the quantity differs from that specified on the packing lists, identify the cause and report the issue to your local Huawei office. -
Page 48: Marking Hole Positions
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 4 Installing Cabinets Figure 4-1 Removing a cabinet from the pallet (1) Pallet Figures of the cabinet and the pallet are for reference only. ----End 4.3 Marking Hole Positions Prerequisites ... -
Page 49: Drilling Holes And Installing Expansion Sleeves
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 4 Installing Cabinets Figure 4-2 Taking down the marking-off template Step 2 Drill holes in the positions for four mounting holes on the marking-off template. Step 3 Mark the hole positions based on the marking-off template, as shown in Figure 4-3. -
Page 50: Hoisting And Installing The Cabinet
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 4 Installing Cabinets Step 4 Remove the bolts, spring washers, and flat washers. Figure 4-4 Drilling holes and installing expansion sleeves (1) M12 bolt (2) Spring washer (3) Flat washer (4) Expansion sleeve... - Page 51 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 4 Installing Cabinets Figure 4-5 Installing lifting eyes Step 3 Bind ropes through the lifting eyes and then hoist the cabinet to an appropriate position, as shown in Figure 4-6. Issue 03 (2014-02-23) Huawei Proprietary and Confidential Copyright ©...
- Page 52 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 4 Installing Cabinets Figure 4-6 Hoisting the cabinet Step 4 Remove the ropes and lifting eyes. Step 5 Reinstall the screws. ----End Issue 03 (2014-02-23) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
-
Page 53: Securing A Cabinet
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 4 Installing Cabinets 4.6 Securing a Cabinet Procedure Step 1 Place the flat washers, spring washers, and expansion bolts into the mounting holes of the cabinet. Step 2 Secure the expansion bolts. - Page 54 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 4 Installing Cabinets Figure 4-8 Loosen screws Step 2 Rotate the protective cover on the door lock to expose the key hole. Step 3 Insert the key into the key hole and rotate it clockwise, and lift the small handle on the lower end of the lock.
- Page 55 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 4 Installing Cabinets Figure 4-9 Unlocking Step 4 Lift the handle, and then rotate it rightwards to open the cabinet door. Figure 4-10 Opening the cabinet door ----End Issue 03 (2014-02-23) Huawei Proprietary and Confidential Copyright ©...
-
Page 56: Installing A Ground Cable
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 5 Installing a Ground Cable Installing a Ground Cable Procedure Step 1 Route the ground cable into the cabinet through the hole at the left bottom of the cabinet. Step 2 Secure the ground cable to the ground bar, as shown in Figure 5-1. - Page 57 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 5 Installing a Ground Cable Figure 5-1 Installing a ground cable (1) Cabinet ground bar (2) Site ground bar ----End Issue 03 (2014-02-23) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
-
Page 58: Installing Components
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 6 Installing Components Installing Components 6.1 Installing a Rectifier Prerequisites Rectifiers are found intact after unpacking and check. In case of any discrepancy, contact your local Huawei office. The filler panel is removed from the slot where you will install a rectifier. -
Page 59: Optional) Installing A Smoke Sensor
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 6 Installing Components Figure 6-1 Installing a rectifier ----End 6.2 (Optional) Installing a Smoke Sensor Procedure Step 1 Locate the smoker sensor fastener inside the cabinet top. Step 2 Install the smoke sensor base onto the fastener. - Page 60 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 6 Installing Components Figure 6-2 Installing a smoke sensor Step 4 Connect one end of the signal cable to the smoke sensor and the other end to the SMOKE port on the UIM panel, as shown in Figure 6-3.
-
Page 61: Optional) Installing A Water Sensor
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 6 Installing Components ----End 6.3 (Optional) Installing a Water Sensor Procedure Step 1 Put the water sensor into the right bottom of the cabinet and secure it with a cable tie, as... -
Page 62: Optional) Installing An Ambient Temperature And Humidity Sensor
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 6 Installing Components Figure 6-5 Connecting the signal cable for the water sensor ----End 6.4 (Optional) Installing an Ambient Temperature and Humidity Sensor Procedure Step 1 Open the cover of the ambient temperature and humidity sensor. - Page 63 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 6 Installing Components Figure 6-6 Connecting the signal cable for the ambient temperature and humidity sensor Step 3 Locate the fastener for the ambient temperature and humidity sensor in the left of the cabinet.
- Page 64 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 6 Installing Components Figure 6-7 Installing an ambient temperature and humidity sensor Number of screws varies as types of ambient temperature and humidity sensors differ. Install the screws as required. Step 5 Close the cover of the ambient temperature and humidity sensor.
-
Page 65: Installing Cables
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 7 Installing Cables Installing Cables Ensure that the upstream AC input circuit breaker is OFF, and attach labels such as "Do not operate." Before installing cables, switch all the circuit breakers to OFF, and remove the fuses from positions where cables will be installed. -
Page 66: Installing The Communications Cables
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 7 Installing Cables ----End 7.2 Installing the Communications Cables 7.2.1 WebUI Management Procedure Step 1 Connect the FE port on the SMU by using a network cable, as shown in Figure 7-2. -
Page 67: Third-Party Nms Management (Over Snmp)
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 7 Installing Cables Networking Mode 2: over RS485 Port Step 1 Connect one end of the network cable to the RS485/RS232 port on the SMU. Step 2 Connect the other end to the MON1 port on the BBU, as shown in Figure 7-4. -
Page 68: Connecting To Huawei Bbu (Over Dry Contacts, M2000 Management)
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 7 Installing Cables ----End 7.2.4 Connecting to Huawei BBU (over Dry Contacts, M2000 Management) Procedure Step 1 Alarm signals are sent over dry contacts. Connect the dry contact signal cable to the... - Page 69 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 7 Installing Cables Figure 7-6 Connecting the UIM02C and the BBU (1) BBU (2) EXT-ALM1 port (3) EXT-ALM0 port In the SRAN site based on the BSC6900, the external alarm port number scope of the two slots is 0 to 7.
-
Page 70: Installing Dc Output Power Cables
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 7 Installing Cables ----End 7.3 Installing DC Output Power Cables Prerequisites Switch off all circuit breakers before installing power cables. Procedure Step 1 Remove the front panel and top epoxy board from the PDU. -
Page 71: Installing Ac Input Power Cables
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 7 Installing Cables Figure 7-7 Installing DC output power cables (1) Load ----End 7.4 Installing AC Input Power Cables If an AC meter and a current transformer are configured, route the AC input power cables through the current transformer first and then connect them to the AC input circuit breaker. -
Page 72: Installing Ac Input Power Cables For The Tp48200A-Dt19C1 Or Tp48200A-Ht19C1
This section elaborates the case in which an AC meter, a current transformer and a maintenance socket are configured. 7.4.1 Installing AC Input Power Cables for the TP48200A-DT19C1 or TP48200A-HT19C1 The following two input systems are supported: 220/380 V AC three-phase, four-wire input system and 220 V AC single-phase input system. - Page 73 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 7 Installing Cables Figure 7-8 Installing 220/380 V AC three-phase, four-wire input power cables (1) Alternating current distribution box (ACDB) ----End Installing 220 V AC Single-Phase Input Power Cables Prerequisites Take the short-circuit copper bar from the fitting bag.
- Page 74 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 7 Installing Cables Procedure Step 1 Remove the insulation cover from the copper bar. Put away the insulation cover and reinstall it after installing the AC input power cables. Step 2 Secure the copper bar to the AC circuit breaker.
- Page 75 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 7 Installing Cables Figure 7-9 Installing 220 V AC single-phase AC input power cables (1) ACDB ----End Issue 03 (2014-02-23) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
-
Page 76: Installing Ac Input Power Cables For The Tp48200A-Dt19C2 And Tp48200A-Ht19C2
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 7 Installing Cables 7.4.2 Installing AC Input Power Cables for the TP48200A-DT19C2 and TP48200A-HT19C2 Installing Cables for a 110 V AC Dual-Live Wire System (L1, L2, N) Procedure Step 1 Route the 110 V AC power cables into the cabinet through the holes at the left bottom of the cabinet. - Page 77 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 7 Installing Cables Figure 7-10 Installing cables for a 110 V AC dual-live wire system (L1, L2, N) (1) ACDB ----End Installing 110 V AC Dual-Live Wire Input Power Cables (L1 and L2)
- Page 78 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 7 Installing Cables Step 3 Secure the AC input power cables to the AC input circuit breaker, as shown in Figure 7-11. Figure 7-11 Installing cables for a 110 V AC dual-live wire system...
- Page 79 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 7 Installing Cables Figure 7-12 Removing the wiring terminal Step 3 Remove the cables from Uc and Un and insulate the cables. Issue 03 (2014-02-23) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
- Page 80 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 7 Installing Cables Figure 7-13 Removing cables Step 4 Take the short-circuit cables from the fitting bag and install them onto the Ub, Uc, and Un. Figure 7-14 Installing the short-circuit cables Step 5 Reinstall the voltage detection wiring terminal for the intelligent electric meter.
- Page 81 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 7 Installing Cables Step 2 Remove the neutral wire from the residual current device (RCD). Step 3 Remove AC input live wire L1 from the UT terminal. Step 4 Connect the removed neutral wire to the position where L1 connects to the UT terminal and connect the removed L1 to the position where the neutral wire connects to the RCD.
-
Page 82: Optional) Installing Batteries
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 8 (Optional) Installing Batteries (Optional) Installing Batteries Smoking and sparks are prohibited near batteries. Switch off battery circuit breakers before installing batteries. Comply with regulations and warnings of the battery manufacturer. -
Page 83: Installing Battery Strings
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 8 (Optional) Installing Batteries Figure 8-1 Battery installation completed 8.1 Installing Battery Strings Prerequisites Ensure that batteries are from the same manufacturer and of the same model and have a close voltage. -
Page 84: Installing Copper Bars Between Batteries
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 8 (Optional) Installing Batteries Figure 8-2 Installing battery strings ----End 8.2 Installing Copper Bars Between Batteries Procedure Step 1 Remove the insulation cover from the batteries. Step 2 Install copper bars between batteries. -
Page 85: Installing Battery Cables
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 8 (Optional) Installing Batteries Figure 8-3 Installing copper bars between batteries ----End 8.3 Installing Battery Cables Prerequisites When installing battery cables, install the negative cable before the positive cable. Procedure Step 1 Take the negative battery cable from the left side of the battery compartment and install the cable to the negative battery wiring terminal. - Page 86 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 8 (Optional) Installing Batteries Figure 8-4 Installing battery cables ----End Issue 03 (2014-02-23) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
-
Page 87: Verifying The Installation
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 9 Verifying the Installation Verifying the Installation 9.1 Checking Hardware Installation Check that all screws, especially those used for electrical connections, are secured. Check that flat washers and spring washers are installed properly. -
Page 88: Commissioning
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 10 Commissioning Commissioning The following commissioning procedure may result in power failure or alarms. Inform the alarm center before and after the procedure. Commissioning involves various technologies, requires trained personnel, and requires compliance with commissioning instructions. -
Page 89: Setting The Display Language
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 10 Commissioning 10.2 Setting the Display Language After powering on the SMU, select English by pressing on the LCD, and then press to enter the standby screen. If you select an undesired language, remove and then insert the SMU. Select a language again after the SMU restarts. -
Page 90: Setting Battery Parameters
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 10 Commissioning Table 10-2 Setting the AC input system Main Second- Third- Fourth- Default Setting Menu Level Level Level Value Value Menu Menu Menu Parameters Power Basic AC Type Three Set to the... -
Page 91: Setting Sensor Parameters
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 10 Commissioning Main Second- Third- Fourth- Default Value Setting Value Menu Level Level Level Menu Menu Menu Rated 150 Ah Rated capacity Capacity of the batteries in a battery string. NOTE... -
Page 92: Optional) Setting Hibernation Parameters
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 10 Commissioning Main Second- Third- Fourth- Default Setting Menu Level Level Level Value Menu Menu Menu Batt. Temp. Sensor 1 Batt. Temp. None Sensor 2 The default values listed in Table 10-4 vary based on the system type. -
Page 93: Optional) Setting Parameters Before Using The Neteco Management
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 10 Commissioning Second- Third-Level Main Menu Level Menu Menu Default Value Setting Value Subnet Mask 255.255.255.0 Set this parameter according to the subnet mask provided by the network administrator. Default Gateway 192.168.0.1... -
Page 94: Setting Parameters Before Using The Snmp Management
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 10 Commissioning Main Second- Third-Level Fourth-Level Menu Level Menu Menu Menu Default Value Setting NetEco Backup IP 192.168.0.10 Set an IP address for the standby NetEco server. NetEco Port 31220 Set a port for the Number NetEco. - Page 95 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 10 Commissioning Information Description User Name To enhance the security, you need a user name and password for authentication if you use SNMPv3. After the authentication succeeds, the MD5 Password SMU can communicate with the NMS.
- Page 96 TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 10 Commissioning Figure 10-1 Login page Step 4 On the System Settings tab page, select SNMP. If the SNMP version is SNMPv1 or SNMPv2c, set SNMP Version to SNMPv1&SNMPv2c under SNMP, and then set SNMP Port Number, Read...
-
Page 97: Connecting The Battery Supply
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 10 Commissioning Figure 10-3 Setting SNMPv3 parameters Step 5 Under SNMP Trap, set Trap Target Address and Trap Port. Step 6 Under Mib files, click Export to export the Mib file and import it to the NMS. -
Page 98: Subsequent Operations
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide 10 Commissioning Step 2 Switch on the battery circuit breakers. Step 3 Switch on the AC input circuit breaker. Step 4 Set all the circuit breakers based on site requirements. Step 5 Observe the power system for 15 minutes. During this period of time, if no alarm (except for the door status alarm) is generated on the LCD of the SMU, the voltages and currents for batteries and loads are normal. -
Page 99: A Associations Between Alarms And Dry Contacts On The Uim
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 A Associations Between Alarms and Dry Contacts on the Installation Guide Associations Between Alarms and Dry Contacts on the UIM Table A-1 Associations between alarms and dry contacts Port Type Silk Screen Associated Alarm... -
Page 100: B Acronyms And Abbreviations
TP48200A-DT19C1 & DT19C2 & HT19C1 & HT19C2 Installation Guide B Acronyms and Abbreviations Acronyms and Abbreviations baseband unit BLVD Battery low voltage disconnection HTTPS Hypertext Transfer Protocol Secure LLVD Load low voltage disconnection Power distribution unit Site monitoring unit SNMP...
