TP48200A-DT19C1, TP48200A-DT19C2,
TP48200A-HT19C1 and TP48200A-HT19C2 Telecom
Power
User Manual
Figure 3-15 TEC04C
(1) External circulation fan
(4) Internal circulation
heat sink
TCUA
TCUA controls the operating of the fans and refrigeration chip, monitors the TEC, and reports
alarms if faults occur. Figure 3-16 shows a TCUA.
Issue 03 (2019-11-15)
(2) External circulation
heat sink
(5) Internal circulation fan
Copyright © Huawei Technologies Co., Ltd.
3 Components
(3) Semiconductor
refrigeration chip
37
