Figure 4-1 Removing a rectifier
Step 4 Push the locking latch on the new rectifier towards the left, and pull out the handle.
Step 5 Place the new rectifier at the entry of the correct slot.
Step 6 Gently slide the rectifier into the slot along the guide rails until it is engaged. Close the handle,
and push the locking latch towards the right to lock the handle, as shown in Figure 4-2.
Figure 4-2 Installing a rectifier
Step 7 Remove the protective gloves.
----End
Follow-up Procedure
Pack the removed component and send it to the local Huawei warehouse.

4.4.2 Replacing an SMU

Prerequisites


Issue 03 (2019-11-15)
The cabinet door key is available.
The new SMU is intact.
