Turning On And Setting The Equipment - CARDIOSTRONG EX40 Assembly And Operating Instructions Manual

3.3

Turning On and Setting the Equipment

1. Connect monitor to the power or press RESET for three seconds and the LCD display will show
all segments with a long beep (1-second-long) and display, i. e., 78.0 (software version) (see fig.
1 and 2).
2. With the +/- buttons, the user can select the programs User 0 to 4 and confirm with MODE
(see fig. 3 to 4). Then set the user data SEX, AGE, HEIGHT and WEIGHT. Press +/- to select the
corresponding values (see fig. 5 to 8). Confirm the settings with MODE.
Figure 1
Figure 3
Figure 5
Figure 7
Figure 2
Figure 4
Figure 6
Figure 8
23
