List of messages after Auto Calibration measurements

Code 31:
Front speakers are not selected properly. Select the front speakers using SPEAKERS and perform the Auto
Calibration again. For details on selecting the front speakers, see
Code 32, Code 33:
Speakers were not detected or not connected properly.
None of the front speakers are connected or only one front speaker is connected.
Either the surround left or surround right speaker is not connected.
A surround back speaker is connected only to the SPEAKERS SURROUND BACK/HEIGHT (FRONT B/BI-
AMP/ZONE 2) R terminal. If connecting only one surround back speaker, connect it to the SPEAKERS
SURROUND BACK/HEIGHT (FRONT B/BI-AMP/ZONE 2) L terminal.
Either the Height1 left or Height1 right speaker is not connected (for STR-ZA3100ES/STR-ZA2100ES).
Either the Height2 left or Height2 right speaker is not connected (for STR-ZA3100ES/STR-ZA2100ES).
Either the Height left or Height right speaker is not connected (for STR-ZA1100ES).
The calibration microphone is not connected. Make sure that the calibration microphone is connected properly
and perform the Auto Calibration again.
If the calibration microphone is connected properly but the error code still appears, the calibration microphone
cable may be damaged.
Code 34:
Speakers are not placed in the proper position. Speakers or the calibration microphone on the right or left may be
placed wrongly.
Code 35:
The measurement result is not match to the speaker pattern you set.
Warning 40:
The measurement process has been completed and a high noise level has been detected. You may be able to
achieve better results if you try the process again in a quiet environment.
Warning 41, Warning 42:
The input from the calibration microphone is too large.
The distance between the speaker and the calibration microphone may be too small. Set them further apart and
perform the measurement again.
Warning 43:
The distance and position of a subwoofer cannot be detected. This may be caused by noise. Try performing the
measurement in a quiet environment.
Warning 44:
Measurement has been completed. However the speakers are not placed in the proper position with respect to each
other.
NO WARNING :
There is no warning information.
