APCI-/CPCI-1500
- Start the set-up program "setup.exe" (double click)
- Select one of the 3 parameters
Proceed as indicated on the screen and read attentively the "Software License"
and "Readme". In "custom", you can select your operating system.
The installation program gives you further instructions.
If the message "Der Keyboard Kernel wurde noch nicht gestartet, ... soll der
Kernel jetzt gestartet werden?" (Problem when installing the system) is
displayed by starting the program, deinstall the ADDIREG program and install
it anew.
6.1.2

Program description

IMPORTANT!
Insert the ADDI-DATA boards to be registered before starting the
ADDIREG program.
If the board is not inserted, the user cannot test the registration.
Once the program is called up, the following dialog box appears.
Board name:
Names of the different registered boards.
When you start the program for the first time, no board is registered in this table.
Base address:
Selected base address of the board.
16
1- typical
2- compact
3- custom

Fig. 6-2: ADDIREG registration program

Technical description Chapter 6
