Technical description
4.3
Options
The board CPCI-1500 is available in 2 versions:
- CPCI-1500-3U: 3U front plane
- CPCI-1500-6U: 6U front plane
4.4
Limit values
Operating temperature: ..................................... 0 to 60°C
Storage temperature: ......................................... -25 to 70°C
Relative humidity: ............................................ 30% to 99% non condensing
Minimum PC requirements (APCI-1500):
- PCI BIOS
- operating system: ........................................... MS DOS 3.3 or >
- bus speed: ....................................................... < 33 MHz
Minimum system requirements (CPCI-1500):
- 32-bit CompactPCI bus (5 V)
- PCI BIOS, PCI 2.1 specification and complying with CompactPCI 2.1
- operating system .............................................MS DOS 3.3 or >
- bus speed .........................................................≤ 33 MHz
Energy requirements
- operating voltage of the PC: ........................... 5V ± 5%
- current consumption in mA (without load): ... typ. See table ± 10%
+ 5 V of the PC
+ 24 V extern
24 V digital input channels
Input type: ......................................................... common ground according
Number of input channels: ............................... 16
Nominal voltage: .............................................. 24 VDC
Input current at nominal voltage: ..................... 6 mA
Chapter 4
APCI-1500
320 mA
-
Windows 3.1, NT, 95, 98
Windows 3.1, NT, 95, 98
CPCI-1500
250 mA
10 mA
to IEC1131-2
APCI-/CPCI-1500
5
