Technical description
APCI-3010, APCI-3016,
APCI-3110 and APCI-3116
Analog I/O board, optically isolated
Edition: 02.04 -08/2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the APCI-3010 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Addi-Data APCI-3010

Summary of Contents for Addi-Data APCI-3010

  • Page 1 DIN EN ISO 9001:2008 certified ADDI-DATA GmbH Airpark Business Center Airport Boulevard B210 77836 Rheinmünster Germany Phone: +49 7229 1847–0 Fax: +49 7229 1847–222 E-mail: info@addi-data.com www.addi-data.com Technical description APCI-3010, APCI-3016, APCI-3110 and APCI-3116 Analog I/O board, optically isolated Edition: 02.04 -08/2016...
  • Page 2 The user is not permitted to make changes to the product beyond the intended use, or to interfere with the product in any other way. ADDI-DATA shall not be liable for obvious printing and phrasing errors. In addition, ADDI DATA, if legally permissible, shall not be liable for personal injury or damage to materials caused by improper installation...

  • Page 3: Warning

    Warning! The following risks result from the improper implementation of the board and from use contrary to the regulations: Personal injury Damage to the board, the PC and peripherals Pollution of the environment. Protect yourself, others and the environment! Read the safety precautions (yellow leaflet) carefully! If this leaflet is not enclosed with the documentation, please contact us and ask for it.

  • Page 4: Table Of Contents

    Contents APCI-3xxx WARNING!..............3 DEFINITION OF APPLICATION ....... 7 Intended use ..............7 Usage restrictions.............7 Limits of use..............7 General description of the board ........8 USER ..............10 Qualification ..............10 Country-specific regulations .........10 HANDLING OF THE BOARD ........11 TECHNICAL DATA..........12 Electromagnetic compatibility (EMC) ......12 Physical set-up of the board ..........12 Limit values..............13...
  • Page 5 Counter ................40 Upward counter..............41 Downward counter ..............41 8.10 Setting a digital output ..........42 STANDARD SOFTWARE ........43 RETURN OR DISPOSAL ........44 10.1 Return ................44 10.2 Disposal of ADDI-DATA waste equipment.......45 APPENDIX ............46 11.1 Glossary .................46 11.2 Index ................50...
  • Page 6 Fig. 7-6: Connection example: Digital inputs........25 Fig. 7-7: Connection example: Digital outputs ........ 26 Fig. 8-1: Block diagram: APCI-3010 and APCI-3016 ......27 Fig. 8-2: Block diagram: APCI-3110 and APCI-3116 ......27 Fig. 8-3: Analog input switch (differential)......... 29 Fig.

  • Page 7: Definition Of Application

    The manufacturer is not liable for damages resulting from improper use. The board must remain in its anti-static packaging until it is installed. Please do not delete the identification numbers of the board or the warranty claim will be invalid. APCI-3xxx = APCI-3010, APCI-3016, APCI-3110 and APCI-3116...

  • Page 8: General Description Of The Board

    General description of the board Characteristics The board has up to 16 single-ended input channels or up to 8 differential input channels for processing analog signals. Table 1-1: Overview Characteristics APCI-3010 APCI-3016 APCI-3110 APCI-3116 Up to 16 (SE) Up to 16 (SE)
  • Page 9 APCI-3xxx Definition of application The screw terminal panel PX 901-AG or the connection box PX-BNC allows the connection of the analog signals to the peripheral through the standard cable ST010. Through the screw terminal panel PX 8000 or PX8001, the standard cable ST 370-16 and the ribbon cable FB 8001 the digital signals are connected to the peripheral.

  • Page 10: User

    User APCI-3xxx USER Qualification Only persons trained in electronics are entitled to perform the following works: installation commissioning maintenance Country-specific regulations Consider the country-specific regulations about: the prevention of accidents electrical and mechanical installations Electromagnetic compatibility (EMC).

  • Page 11: Handling Of The Board

    APCI-3xxx Handling of the board HANDLING OF THE BOARD Fig. 3-1: Correct handling Hold the board cautiously at the outer end and at the slot bracket. Do not touch the surface of the board!

  • Page 12: Technical Data

    Weight: ............approx. 160 g Installation in: ........... 32-/64-bit PCI slot 3.3 V / 5 V Front connector: ........37-pin SUB-D male connector Additional connectors: APCI-3010, APCI-3016, APCI-3110, APCI-3116: ......50 pin male connector for TTL I/O and 24 V optically isolated I/O...

  • Page 13: Limit Values

    APCI-3xxx Technical data Accessories For analog I/O: Cable: ............- ST010 Screw terminal panel: ........ - PX 901-AG or connection box: ........- PX-BNC For digital I/O: Cable: ............- FB 8001 - ST370-16 Screw terminal panel: ........ - PX8001 NOTICE! The connection lines must be installed in such a way that they are protected against mechanical loads.

  • Page 14: Analog Inputs

    Technical data APCI-3xxx 4.3.1 Analog inputs Number of channels: ........16 analog inputs Resolution (APCI-3010 and APCI-3110): 12-bit Resolution (APCI-3016 and APCI-3116): 16-bit Max. throughput rate: ........ 200 kHz (total sampling rate with all channels) Optical isolation: ........1000 V (1 second tested) Temperature drift: ........10 ppm/K...

  • Page 15: Digital Outputs

    APCI-3xxx Technical data Logic input level: ........UH (max.): 30 V UH (min.): 19 V UL (max.): 14 V UL (min.): Input frequency: .........1 MHz (max.) at 24 V Interruptible inputs:........Not available 4.3.4 Digital outputs (24 V Number of channels: ........4 digital outputs Optical isolation: ........1000 V (1 s tested) Output type:..........High-Side (load to GND) (UDN2987)

  • Page 16: Timer, Counter And Watchdog

    Resolution: ..........16-bit Input: ............Low/High (programmable) Output: ............Low/High (programmable) Operation mode:.........Mode 2, Mode 3 (programmable) Watchdog: Number (APCI-3010, APCI-3016):..1 Number (APCI-3110, APCI-3116):..2 Watchdog depth: ........16-bit Programmability: ........1 μs to 65535 s Time base: ..........µs, ms, s (programmable) Monitoring period: ........1 to 4095 µs, ms, s...

  • Page 17: Installation Of The Board

    APCI-3xxx Installation of the board INSTALLATION OF THE BOARD Risk of injury! Please follow the safety precautions! An improper handling of the board may cause property damage and injury. Opening the PC ♦ Switch off your PC and all the units connected to it. ♦...

  • Page 18: Plugging The Board Into The Slot

    Installation of the board APCI-3xxx Plugging the board into the slot ♦ Insert the board vertically into the chosen slot. Fig. 5-2: Inserting the board ♦ Fasten the board to the rear of the PC housing with the screw which was fixed on the back cover.

  • Page 19: Driver Installation

    Information on how to select and download the appropriate driver can be found in the document “Quick installation PC boards” (see PDF link). The installation of drivers of the type “ADDI-DATA Multiarchitecture Device Drivers 32-/64-Bit for x86/AMD64” as well as the installation of the corresponding samples is described in the installation instructions (see PDF link).

  • Page 20: Connecting The Peripherals

    Connecting the peripherals APCI-3xxx CONNECTING THE PERIPHERALS Connector pin assignment Fig. 7-1: 37 pin SUB-D male connector (analog inputs and outputs)

  • Page 21: Fig. 7-2: 50-Pin Connector (Ttl I/O)

    APCI-3xxx Connecting the peripherals Fig. 7-2: 50-pin connector (TTL I/O) NOTICE! The numbering of the 50-pin SUB-D connector corresponds to the usual numbering as printed on the connector for the LP mounting. However, on the connector for the connection to a ribbon cable a different numbering is printed as on the connector (corresponds to the numbering of the ribbon cable).
  • Page 22 Connecting the peripherals APCI-3xxx Table 7-1: Connection of the digital inputs and outputs (24 V and TTL) FB8001 Board Pin No. Pin No. Pin description (50-pin SUB-D (50-pin header) male connector) +24 V Output channel 0 Output channel 1 Output channel 2 Output channel 3 Input channel 0 (-) Input channel 0 (+)

  • Page 23: Connection Of The Screw Terminal Panels

    APCI-3xxx Connecting the peripherals FB8001 Board Pin No. Pin No. Pin description (50-pin SUB-D (50-pin header) male connector) TTL channel 12 TTL channel 13 TTL channel 14 TTL channel 15 TTL channel 16 TTL channel 17 TTL channel 18 TTL channel 19 TTL channel 2 TTL channel 20 TTL channel 21...

  • Page 24: Connection Examples

    Connecting the peripherals APCI-3xxx Fig. 7-3: Connection of the screw terminal panel NOTICE! Plug the FB8001 cable into the connector of the board by inserting the red (or blue or black) cable line into pin 1. Connection examples 7.3.1 Analog inputs Fig.

  • Page 25: Analog Outputs (Only Apci-3110 And Apci-3116)

    APCI-3xxx Connecting the peripherals 7.3.2 Analog outputs (only APCI-3110 and APCI-3116) Fig. 7-5: Connection example: Analog outputs 7.3.3 Digital inputs (24 V) Fig. 7-6: Connection example: Digital inputs...

  • Page 26: Digital Outputs (24 V)

    Connecting the peripherals APCI-3xxx 7.3.4 Digital outputs (24 V) Fig. 7-7: Connection example: Digital outputs...

  • Page 27: Functions Of The Board

    Fig. 8-1: Block diagram: APCI-3010 and APCI-3016 Fig. 8-2: Block diagram: APCI-3110 and APCI-3116 Analog inputs There are 16 analog input channels on the boards – the resolution of the APCI-3010 and APCI-3110 is 12-bit and of the APCI-3016 and APCI-3116 16-bit.

  • Page 28: Overview

    After the signals are transferred over a filter (RC-component) to a multiplexer (time multiplexed system), they are lead over a programmable instrumental gain to a 16-bit A/D converter (or 12-bit for APCI-3010 and APCI-3110). Data acquisition with the APCI-3xxx is based on a time-multiplex system.

  • Page 29: Analog Input Switch (Differential Inputs)

    APCI-3xxx Functions of the board Please note: During the switching of the voltage range from unipolar to bipolar or from bipolar to unipolar there is a longer settling time of the measuring chain. 8.2.3 Analog input switch (differential inputs) The input impedance is the input resistance (10 Ω) of the PGA and the connected capacities (C and C...

  • Page 30: Simple Mode

    Continuous hardware triggered scan with timer delay The following section describes the above mentioned scan modes more detailed: a) Single software scan The user interrupt routine is called after the last IRQ (=ADDI-DATA driver). Note: In the scan mode no DMA functionality is used!
  • Page 31 APCI-3xxx Functions of the board b) Single hardware triggered scan This scan can be triggered with rising or falling edge (software initializes it). c) Continuous software scan...
  • Page 32 Functions of the board APCI-3xxx d) Continuous software scan with timer delay e) Continuous hardware triggered scan Note: In this scan mode the external signal triggers only one scan at a time! f) Continuous hardware triggered scan with timer delay...

  • Page 33: Sequence Modes (With Dma)

    APCI-3xxx Functions of the board Sequence modes (with DMA) There are 2 sequence modes that are shown in the following two examples: a) Simple sequence mode (example 1 and 2) b) Sequence mode with delay (example 1 and 2) Note: The sequence mode always uses DMA! a) Simple sequence mode Simple sequence mode –...
  • Page 34 Functions of the board APCI-3xxx dw_NbrOfChannel dw_SequenceChannelArray = 0, 1, 2, 3, 4 b_DelayTimeMode = ADDIDATAG_DELAY_NOT_USED dw_SequenceCounter dw_InterruptSequenceCounter= 2 b) Sequence mode with delay Sequence mode with delay - example 1 The interrupt occurs after the second sequence (10 acquisitions) and the acquisition is stopped.

  • Page 35: Auto Refresh Mode

    APCI-3xxx Functions of the board dw_DelayTime = 20 dw_SequenceCounter dw_InterruptSequenceCounter= 2 Auto refresh mode The analog acquisition is initialized and writes the values of the channels into a storage location on the APCI-3xxx. The PC reads the data asynchronous to the acquisition. Analog outputs There are 4 analog output channels with a resolution of 12-bit and a precision of 11-bit on the APCI-3110 and APCI-3116.

  • Page 36: Fig. 8-4: Reaction Time Of The Analog Outputs

    Functions of the board APCI-3xxx Fig. 8-4: Reaction time of the analog outputs When the computer is switched on, the analog outputs are temporarily in an undefined state. It is thus essential that the computer is switched on before the connected peripherals. After the Power ON reset of the computer, a voltage of 0 V is applied to all analog outputs.

  • Page 37: Digital Inputs

    APCI-3xxx Functions of the board Digital inputs The inputs are designed for the acquisition of external signal states: The input information is loaded as numerical value into a memory unit of the PC by software. This numeric value calculates the state of the inputs signals. 24 V optically isolated inputs They correspond to the 24 V industrial standard (IEC1131-2): logic"1"...

  • Page 38: Digital Outputs

    Functions of the board APCI-3xxx Digital outputs The APCI-3xxx has 4 optically isolated outputs. The positive logic is applied: logic"1": Sets the output by software. logic"0": Resets the output. NOTICE! The supply unit for the external voltage supply of the board must supply the power that is needed for your application.

  • Page 39: Ttl Inputs And Outputs

    APCI-3xxx Functions of the board TTL inputs and outputs The board APCI-3xxx has 24 TTL channels that are divided into three ports: Table 8-1: TTL I/O (ports) Port Description Channel Output Channel 0-7 Port 0 Input Channel 8-15 Port 1 Programmable I/O Channel 16-23 Port 2...

  • Page 40: Timer

    Functions of the board APCI-3xxx Timer The 16-bit timer is a downwards counter that can generate an interrupt after the reload value (timeout). With the timer a time base is provided independent from the PC clock, with which for example operations can be synchronized.

  • Page 41: Upward Counter

    APCI-3xxx Functions of the board Upward counter Fig. 8-9: Run down of the upward counter After reaching the reload value, the counting value is set on 0 and continues to be counted. At an overflow an interrupt can be generated. Downward counter Fig.

  • Page 42: Setting A Digital Output

    Functions of the board APCI-3xxx 8.10 Setting a digital output At the run down of the counter/timer/watchdog a digital output (24 V) can be set. Here also the output level can be defined. The output will be enabled for an (input) clock. Fig.

  • Page 43: Standard Software

    APCI-3xxx Standard software STANDARD SOFTWARE The API software functions supported by the board are listed in an HTML document. A description on how to access the respective file can be found in the document “Quick installation PC boards” (see PDF link), in the chapter “Standard software”.

  • Page 44: Return Or Disposal

    Place the board in an ESD protective cover. Then pack it in a cardboard box so that it is well-protected for shipping. Send the packed board together with your details to: ADDI-DATA GmbH Airpark Business Center Airport Boulevard B210 77836 Rheinmünster Germany •...

  • Page 45: Disposal Of Addi-Data Waste Equipment

    APCI-3xxx Return or disposal 10.2 Disposal of ADDI-DATA waste equipment ADDI-DATA organises the disposal of ADDI-DATA products that were put on the German market after 13 August 2005. If you want to return waste equipment, please e-mail your request to: rohs@addi-data.com.

  • Page 46: Appendix

    Appendix APCI-3xxx APPENDIX 11.1 Glossary Table 11-1: Glossary Term Description A/D converter = ADC An electronic device that produces a digital output directly proportional to an analog signal output. Acquisition The process by which data is gathered by the computer for analysis or storage.
  • Page 47 APCI-3xxx Appendix Term Description Gain The factor by which an incoming signal is multiplied. Ground A common reference point for an electrical system. Impedance The reciprocal of admittance. Admittance is the complex ratio of the voltage across divided by the current flowing through a device, circuit element, or network.
  • Page 48 Appendix APCI-3xxx Term Description Optical isolation The technique of using an optoelectric transmitter and receiver to transfer data without electrical continuity, to eliminate high-potential differences and transients. Output voltage The nominal voltage output reading when shaft is rotated to full range, expressed in volts DC /Vo DC) Parameter The parameters of a control comprise all for the control process required numeric values, e.g.
  • Page 49 APCI-3xxx Appendix Term Description Signal delay The change of a signal affects the following circuitries with finite velocity; the signal will be delayed. Besides the signal delay times that are not wanted, the signal delay can be extended by time switches and delay lines. Simple mode The software initializes and starts the A/D conversion and after this step it reads the digital value of one or more...

  • Page 50: Index

    Appendix APCI-3xxx 11.2 Index Accessories 13 Installation of the board 17 Block diagram 27 Limit values 13 Characteristics 8 Connection example Closing 18 Analog inputs 24 PC requirements 13 Analog outputs 25 Digital inputs 25 Digital outputs 26 Connector pin assignment Repair 46 numbering 21 Return 46...

This manual is also suitable for:

Apci-3116Apci-3016Apci-3110
