Technical description
9.2
DIN 66001- Graphical symbols
In this chapter are all the software functions (API) necessary for the operation of
the APCI-/CPCI-1500 board.
To illustrate these functions, we designed diagrams with the graphical symbols
listed below.
The user will hence have a quick outlook of the hierarchy between the different
functions.
Chapter 9
Process, general
(including input channels and output channels)
Decision
Selection unit
(e.g.: switch)
Loop limit
Beginning
Loop limit
End
APCI-/CPCI-1500
37
