Addi-Data APCI-3003 Technical Description

Analog input board, optically isolated
Hide thumbs Also See for APCI-3003:
Table of Contents

Advertisement

Quick Links

Download this manual
TECHNICAL
DESCRIPTION
APCI-3003
Analog input board, optically isolated
Edition: 02.03-05/2017
DIN EN ISO 9001:2008 certified

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the APCI-3003 and is the answer not in the manual?

Questions and answers

Related Manuals for Addi-Data APCI-3003

Summary of Contents for Addi-Data APCI-3003

  • Page 1 TECHNICAL DESCRIPTION APCI-3003 Analog input board, optically isolated Edition: 02.03-05/2017 DIN EN ISO 9001:2008 certified...
  • Page 2 The content of this manual and the technical product data may be changed without prior notice. ADDI-DATA GmbH reserves the right to make changes to the technical data and the materials included herein.

  • Page 3: Warning

    If the instructions are ignored, the board, the PC and/or peripherals may be destroyed. WARNING! Designates a possibly dangerous situation. If the instructions are ignored, the board, the PC and/or peripherals may be destroyed and persons may be endangered. www.addi-data.com...

  • Page 4: Table Of Contents

    Digital inputs..........................27 Digital outputs ..........................28 Timer...............................29 Standard software ......................30 Return or disposal......................31 Return .............................31 Disposal of ADDI-DATA waste equipment...................32 Technical data and limit values ..................33 Electromagnetic compatibility (EMC) ...................33 Mechanical structure ........................33 Version............................34 Options ............................34 Limit values.............................34 7.5.1...
  • Page 5 Slot: Insert the board.......................11 Fig. 3-3: PC housing: Fasten the board ....................11 Fig. 3-4: APCI-3003: Connection of the screw terminal panels ............12 Fig. 3-5: 15-pin D-Sub male connector (analog inputs) ...............13 Fig. 3-6: ST3003-A cable: 37-pin D-Sub male connector (analog inputs) ...........13 Fig.

  • Page 6: Chapter Overview

    Chapter overview APCI-3003 Chapter overview In this manual, you will find the following information: Chapter Content Important information on the application, the user and on handling the board Brief description of the board (features, block diagram) Detailed information on the insertion of the board, connection of the accessories (including pin assignment) and driver installation Tip: Print out this chapter to have help at hand for inserting and installing the board.

  • Page 7: Definition Of Application, User, Handling

    1.1 Definition of application 1.1.1 Intended use The board APCI-3003 must be inserted in a PC with PCI slots which is used as electrical equipment for measurement, control and laboratory pursuant to the standard EN 61010-1 (IEC 61010-1). The used personal computer (PC) must fulfil the requirements of IEC 60950-1 or EN 60950-1 and EN 55022 or IEC/CISPR 22 and EN 55024 or IEC/CISPR 24.

  • Page 8: Country-Specific Regulations

    E-mail: info@addi-data.com Manual and software download from the Internet The latest versions of the technical manual and the standard software for the board APCI-3003 can be downloaded for free at: www.addi-data.com. NOTICE! Before using the board and in case of malfunction during operation, check if there is an update (manual, driver) available.

  • Page 9: Brief Description

    • Various acquisition modes (with DMA function as well) and trigger settings • Optical isolation between the channels: 1000 V • Input filters • Overvoltage protection • Protection against high-frequency EMI 2.2 Block diagram Fig. 2-1: APCI-3003: Block diagram www.addi-data.com...

  • Page 10: Insertion And Installation Of The Board

    Insertion and installation of the board APCI-3003 3 Insertion and installation of the board 3.1 Insertion of the APCI board Risk of injury! Please follow the safety precautions! An improper handling of the board may cause property damage and injury.

  • Page 11: Inserting The Board

    Insertion and installation of the board APCI-3003 3.1.3 Inserting the board Insert the board vertically from above into the selected slot. Fig. 3-2: Slot: Insert the board Fasten the board to the rear of the PC housing using the screw which held the back cover in place.

  • Page 12: Connecting The Accessories

    3.2 Connecting the accessories 3.2.1 Connection of the screw terminal panels The APCI-3003 board receives analog signals from the peripherals via the screw terminal panel PX901-AG und the cable ST3003-A, which needs to be connected to the 15-pin D-Sub male connector of the board.

  • Page 13: Pin Assignment

    Insertion and installation of the board APCI-3003 3.2.2 Pin assignment 1) Analog inputs Fig. 3-5: 15-pin D-Sub male connector (analog inputs) Fig. 3-6: ST3003-A cable: 37-pin D-Sub male connector (analog inputs) www.addi-data.com...

  • Page 14: Fig. 3-7: 15-Pin D-Sub Female Connector (Digital I/O)

    Insertion and installation of the board APCI-3003 2) Digital I/O Fig. 3-7: 15-pin D-Sub female connector (digital I/O) Fig. 3-8: ST3003-D cable: 37-pin D-Sub male connector (digital I/O) www.addi-data.com...

  • Page 15: Connection Principle

    Insertion and installation of the board APCI-3003 3.2.3 Connection principle Fig. 3-9: Connection principle With the PC-Diff option (see Chapter 7.4), the board has to be placed at the end of the current loop so that the voltage (U GND) at the differential input pin is 12 V max. relating to GND.

  • Page 16: Connection Examples

    Insertion and installation of the board APCI-3003 3.2.4 Connection examples 1) Analog inputs Fig. 3-11: Connection example (differential inputs) * Optional connection if there is no GND connection available at the signal source NOTICE! Due to the very high impedance of the analog inputs, the measurement result is undefined, i.e.

  • Page 17: Fig. 3-12: Connection Example (Digital Inputs)

    Insertion and installation of the board APCI-3003 2) Digital I/O (24 V) Fig. 3-12: Connection example (digital inputs) www.addi-data.com...

  • Page 18: Driver Installation

    Information on how to select and download the appropriate driver can be found in the document “Quick installation PC boards” (see PDF link). The installation of drivers of the type “ADDI-DATA Multiarchitecture Device Drivers 32-/64-Bit for x86/AMD64” as well as the installation of the corresponding samples is described in the installation instructions (see PDF link).

  • Page 19: Function Description

    4 Function description 4.1 Analog inputs Up to 4 differential signals can be connected to the APCI-3003 board. Each channel has its own A/D converter. A high throughput rate (400 kHz per channel) can be reached by a simultaneous conversion of all four channels.

  • Page 20: Analog Input Circuit

    Ω Ω not fitted) 4.1.3 Input modes of the analog inputs For analog input, four differential channels are available on the APCI-3003 board. The acquisition can be carried out in the following modes: 1) Simple mode 2) Scan mode 3) Sequence mode (with DMA function) 4) Auto-refresh mode.
  • Page 21 Function description APCI-3003 1) Simple mode The software initialises and starts the A/D conversion. After that it reads in the digital value from one or more channels. This can be done either with or without interrupt. 2) Scan mode There are 6 different scan modes:...
  • Page 22 Function description APCI-3003 a) Software-triggered single scan The user interrupt routine is called up after the last IRQ (= ADDI-DATA driver). NOTICE! Please note that the DMA function is not used in Scan mode. b) Hardware-triggered single scan This scan can be triggered with a rising or falling edge (initialisation through software).
  • Page 23 Function description APCI-3003 d) Software-triggered continuous scan with timer delay e) Hardware-triggered continuous scan NOTICE! Please note that in this scan mode, the external signal triggers only one scan at a time. f) Hardware-triggered continuous scan with timer delay www.addi-data.com...
  • Page 24 Function description APCI-3003 3) Sequence mode (with DMA function) Two sequence modes are available, which are described below with two examples each: a) Simple sequence mode (examples 1 and 2) b) Sequence mode with delay (examples 1 and 2) NOTICE! Please note that the Sequence mode always uses the DMA function (Direct Memory Access).
  • Page 25 Function description APCI-3003 Simple sequence mode - example 2 Here, the interrupt is released after 2 sequences (10 acquisitions). The entire acquisition is completed via the following function: i_PCI3003_StopAnalogAcquisition b_ChannelCount = 4 pb_Channel = 0, 1, 2, 3 dw_SequenceCount = 0...
  • Page 26 Function description APCI-3003 Sequence mode with delay - example 2 In this example, the delay between the end of a sequence and the start of the next one is 20 μs. b_ChannelCount = 4 pb_Channel = 0, 1, 2, 3...

  • Page 27: Digital Inputs

    Function description APCI-3003 4.2 Digital inputs The digital inputs acquire external signal states. The input information is loaded as a numeric value in a memory cell of the system via the driver function. This numeric value represents the status of the input signals.

  • Page 28: Digital Outputs

    Function description APCI-3003 4.3 Digital outputs For the digital outputs, positive logic is used: • Logic “1”: Set output through software • Logic “0”: Reset output The maximum supply voltage is 30 V. Each output can switch a current of 50 mA. The total current of all outputs is limited to 300 mA by a polyswitch fuse element.

  • Page 29: Timer

    APCI-3003 4.4 Timer The APCI-3003 board is fitted with a timer. Independently from the PC clock, the timer provides a time base to synchronise operations, for example. The 16-bit timer is a downward counter which can release an interrupt after the programmed cycle time has elapsed (time-out).

  • Page 30: Standard Software

    Standard software APCI-3003 5 Standard software The API software functions supported by the board are listed in an HTML document. A description of how to access the respective file can be found in the document “Quick installation PC boards” (see PDF link), in the chapter “Standard software”.

  • Page 31: Return Or Disposal

    Return or disposal APCI-3003 6 Return or disposal 6.1 Return If you need to return your board, you should read the following checklist before. Checklist for returning the board: • Specify the reason for returning your board (e.g. exchange, modification, repair), the serial number of the board, the contact person in your company including his/her telephone extension and e-mail address, as well as the mailing address for a potential new delivery.

  • Page 32: Disposal Of Addi-Data Waste Equipment

    Return or disposal APCI-3003 6.2 Disposal of ADDI-DATA waste equipment ADDI-DATA organises the disposal of ADDI-DATA products that were put on the German market after 13 August 2005. If you want to return waste equipment, please e-mail your request to: rohs@addi-data.com.

  • Page 33: Technical Data And Limit Values

    The board APCI-3003 is suited for installation in personal computers (PCs) which comply with the European EMC directive. The board APCI-3003 complies with the European EMC directive. The tests were carried out by a certified EMC laboratory in accordance with the standard from the EN 61326 series (IEC 61326).

  • Page 34: Version

    The specific version name can be found on the type label at the slot bracket of your board. 7.4 Options Please specify the number of channels when ordering one of the following options for the APCI-3003 board! Table 7-1: Options...

  • Page 35: Analog Inputs

    Technical data and limit values APCI-3003 7.5.1 Analog inputs Number of inputs: 4 (differential) Resolution: 15-bit (unipolar) 16-bit (bipolar) Input range: 0-10 V (unipolar), 1 LSB = 153 μV ± 10 V (bipolar), 1 LSB = 305 μV 0-20 mA (optional): if unipolar, gain = 2...

  • Page 36: Digital Outputs (24 V)

    Technical data and limit values APCI-3003 Max. input frequency (at nominal voltage): 1 MHz Logic input levels: : 30 V : 19 V : 14 V : 0 V 7.5.3 Digital outputs (24 V) Number of outputs: Output type: Open Collector (ULN2803A)

  • Page 37: Appendix

    Appendix APCI-3003 8 Appendix 8.1 Glossary A/D converter The rising edge is the transition from the status An A/D converter is an electronic device, often “0” to “1”; the falling edge is the opposite an integrated circuit that produces a digital transition.
  • Page 38 Appendix APCI-3003 Calibration of the INL error alone is not Operating voltage possible. The operating voltage is the voltage to the device in sustained operation. It must not exceed the maximum sustained voltage, and all Input impedance unfavourable operating conditions, such as...
  • Page 39 Appendix APCI-3003 Trigger A trigger is a pulse or signal for starting or stopping a special task. Triggers are often used for controlling data acquisition. = Transient Voltage Suppression www.addi-data.com...

  • Page 40: Index

    Appendix APCI-3003 8.2 Index Accessories 33 Intended use 7 Connection 12 Limit values 34 Block diagram 9 Options 34 Board Pin assignment 13 Handling 8 Repair 31 Insertion 10 Return 31 Connection example Scan mode Analog inputs 16 Hardware-triggered continuous scan 23...

  • Page 41: Contact And Support

    Contact and support APCI-3003 9 Contact and support Do you have any questions? Write or call us: Address: ADDI-DATA GmbH Airpark Business Center Airport Boulevard B210 77836 Rheinmünster Phone: +49 7229 1847-0 Fax: +49 7229 1847-222 E-mail: info@addi-data.com Manual and software download from the Internet: www.addi-data.com...
