Technical description Chapter 6 APCI-/CPCI-1500

Fig. 6-4: PCI Boards

With this option you can select the identifier string by entering the
corresponding number and activating with "OK".
With one click on "cancel" you can select the former string.
Save:
Saves the parameters and registers the board.
Restore:
Reactivates the last saved parameters and registration.
ADDIDriver Board Manager (only for boards with ADDIPACK):
Under Edit/ADDIDriver Board Manager you can check or change the current
settings of the board set through the ADDEVICE Manager.
ADDevice Manager starts. The windows displayed lists all resources available
for the virtual board.
Test registration:
Controls if there is a conflict between the board and other devices.
A message indicates the parameter which has generated the conflict. If there is
no conflict, "OK" is displayed.
Deinstall registration:
Deinstalls the registrations of all board listed in the table.
Print registration:
Prints the registration parameter on your standard printer.
Quit:
Quits the ADDIREG program.
19
