Technical description
Task:
Sets the output channel which has been passed with b_Channel.
Setting an output channel means setting an output channel on high.
Switching on the digital output memory (ON)
see function "i_APCI1500_SetOutputMemoryOn (...)
The output channel 1 is set. The others output channels hold their state.
Switching off the digital output memory (OFF)
see function "i_APCI1500_SetOutputMemoryOff (...)
The output channel 1 is set. The others output channels are reset.
If you have switched off the digital output memory (OFF), all the others input
channels are set to "0".
Return value:
0: No error
-1: Handle parameter of the board is wrong
-2: Input number is not between 1 and 16

4) i_APCI1500_Set1DigitalOutputOff (...)

Syntax :
<Return value> = i_APCI1500_Set1DigitalOutputOff
Parameters:
BYTE
BYTE
Task:
Resets the output channel you have passed with b_Channel. Resetting an output
channel means setting to low.
IMPORTANT!
You can use this function only if the digital output memory is ON.
See function i_APCI1500_SetOutputMemoryOn (..).
Return value:
0: No error
-1: The handle parameter of the board is wrong
-2: The input number is not between 1 and 16
-3: Digital output memory OFF.
First use the function "i_APCI1500_SetOutputMemoryOn"
Chapter 9
b_Channel= 1
b_Channel= 1
b_BoardHandle
b_Channel
(BYTE b_BoardHandle,
BYTE b_Channel)
Handle of the xPCI-1500
Number of the output channel you want to
reset (1 to 16)
APCI-/CPCI-1500
79
