Technical description

Input frequencies

The input frequency for the timer is selected through the software function
i_APCI1500_InitTimerInputClock (...)
Available frequencies:
111.86 kHz ± 100 ppm,
3.49 kHz ± 100 ppm,
1.747 kHz ± 100 ppm.
IMPORTANT!
The timer component internally operates with half of the input frequency.

Data

Approximate watchdog times:
17.9 µs
574 µs
1.14 ms

Option (only implemented for the APCI-1500)

The counter input channels 1, 2 and 3 can be equipped with fast optical couplers.
The maximum input frequency is then 140 kHz. (Standard frequency: 10 kHz)
Chapter 8
1175 ms
37.65 s
74.9 s
Input frequency
111.86 kHz
3.49 kHz
1.747 kHz
APCI-/CPCI-1500
35
