Table 9-3: Interrupt Mask - Addi-Data ADDINUM CPCI-1500 Technical Description

Technical description
The following errors are possible
- overtemperature
- short-circuit
- no voltage is available
If several boards are operated and if they have to react to interrupts, the variable
b_BoardHandle returns the identification number (handle) of the board which
has generated the interrupt.
The user interrupt routine must have the following syntax:
VOID v_FunctionName (BYTE
v_FunctionName
b_BoardHandle
b_InterruptMask
b_InputChannelNbr
The user can give another name for v_FunctionName, b_BoardHandle,
b_InterruptMask, b_InputChannelNbr.
Chapter 9
BYTE
BYTE
Name of the user interrupt routine
Handle of the xPCI-1500 which has generated the
interrupt
Mask of the events which have generated the interrupt.
If an interrupt is generated with a Mask 0000 0001 and if
you use the OR-PRIORITY logic, this variable gives the
input number, which have generated the interrupt.

Table 9-3: Interrupt mask

Mask
0000 0001 Event 1 has occurred
0000 0010 Event 2 has occurred
0000 0100 Counter/timer 1 has run down
0000 1000 Counter/timer 2 has run down
0001 0000 Counter 3 has run down
0010 0000 Watchdog has run down
0100 0000 Voltage error
1000 0000 Short-circuit error
b_BoardHandle,
b_InterruptMask,
b_InputChannelNbr)
Meaning
APCI-/CPCI-1500
49
