Driver Installation; Driver Installation Under Ms-Dos; Driver Installation Under Windows 3.11 Und Windows Nt; Fig. 6-5: Driver Installation - Addi-Data ADDINUM CPCI-1500 Technical Description

Technical description
6.2

Driver installation

Remark: The CPCI-1500 board is entirely compatible with the APCI-1500
board regarding the software installation and the device driver. The program
ADDIREG will thus make no difference between the systems (PCI board or
Compact PCI board). The API functions of the device driver are also the same.
6.2.1

Driver installation under MS-DOS

- Copy the contents of APCI1500\Dos\Disk1 or on a disk.
If several disks are to be used, the directory content is stored in several sub-
directories (Disk1, Disk2, Disk3...).
- Insert the (first) disk into a driver and change to this drive.
- Enter <INSTALL>.
The installation program gives you further instructions.
6.2.2

Driver installation under Windows 3.11 und Windows NT

- Change to the CD drive.
- Select the directory APCI1500\Win-XP-2000-NT-98\driver\Disk1 or
APCI1500\Win311\driver\Disk1.
- Start the set-up program "setup.exe" (double click)
- Select one of the 3 parameters
Proceed as indicated on the screen and read attentively the "Software License"
and "Readme". In "custom", you can select your operating system.
The installation program gives you further instructions.
Chapter 6

Fig. 6-5: Driver installation

1- typical
2- compact
3- custom
APCI-/CPCI-1500
21
