Fig. 6-3: Configuring A New Board - Addi-Data ADDINUM CPCI-1500 Technical Description

APCI-/CPCI-1500
Buttons:
Edit
Selection of the highlighted board with the different parameters set in the text boxes.
Click on "Edit" to activate the data or click twice on the selected board.
Insert:
When you want to insert a new board, click on "Insert". The following dialog
window appears:
All boards you can register are listed on the left. Select the wished board. (The
corresponding line is highlighted).
On the right you can read technical information about the board(s).
Activate with "OK"; You come back to the former screen.
Clear:
You can delete the registration of a board. Select the board to be deleted and
click on "Clear".
Set:
Sets the parametered board configuration. The configuration should be set
before you save it.
Cancel:
Reactivates the former parameters of the saved configuration.
Default:
Sets the standard parameters of the board.
More information:
You can change the board specific parameters like the identifier string, the COM
number, the operating mode of a communication board, etc...
If your board does not support these information, you cannot activate this button.
1 "x": Keyboard shortcuts; e.g. "Alt + e" for Edit
18
1
:

Fig. 6-3: Configuring a new board

Technical description Chapter 6
