READY FOR USE

Multi Frame is folded when delivered but is un-
folded very easily:
1) Push in the buttons (A) in both sides of the
handle and fold out the push brace
2) The frame is folded out by lifting the push
brace. Fold out until the lock fitting "clicks"
into place on either side of of the frame (B)
3) The push brace is adjusted by pushing in the
buttons (A) in both sides of the handle and
lifting the handle into the required position.
Your Multi Frame is now ready for use.
Check that the locking pins (B) are com-
pletely locked in both sides before using
the wheel chair.
Please be careful not to get your fingers
caught when folding out the frame.
Warning - Entrapment hazard be careful
not to get fingers caught between the front
wheel and the fork
Correct lifting point. Always use the correct
lifting techniques and aids for this purpose.
