Valor LX1 Installation Manual

Hide thumbs Also See for LX1:

Quick start manual (3 pages)

Installation manual (17 pages)

Installation manual (7 pages)

Table Of Contents

Table of Contents

Quick Links

Download this manual

Installation Manual

LX1

Installer: Leave this manual with the appliance.

Consumer: Retain this manual for future reference.

WARNING:

FIRE OR EXPLOSION HAZARD

Failure to follow safety warnings

exactly could result in serious

injury, death, or property damage.

Do not store or use gasoline or other

ﬂ ammable vapors and liquids in the

vicinity of this or any other appliance.

WHAT TO DO IF YOU SMELL GAS

Do not try to light any appliance.

▪

DANGER

4007364-01

Direct Vent Zero Clearance

Gas Fireplace

natural gas

2100PKN

propane gas 2100PKP

PIER

▪

Installation and service must be

performed by a qualiﬁ ed installer, service

agency or the gas supplier.

Hot glass

will cause burns.

Do not touch glass

until cooled.

Never allow children

to touch glass.

Do not touch any electrical switch; do

not use any phone in your building.

Leave the building immediately.

Immediately call your gas supplier from

a neighbor's phone. Follow the gas

supplier's instructions.

If you cannot reach your gas supplier,

call the ﬁ re department.

A barrier designed to reduce

the risk of burns from the hot

viewing glass is provided with this

appliance and must be installed for

the protection of children and

other at-risk individuals.

Table of Contents

Summary of Contents for Valor LX1

Page 1 Installation Manual Direct Vent Zero Clearance Gas Fireplace natural gas 2100PKN propane gas 2100PKP PIER Installer: Leave this manual with the appliance. Consumer: Retain this manual for future reference. Do not touch any electrical switch; do ▪ WARNING: not use any phone in your building. FIRE OR EXPLOSION HAZARD Leave the building immediately.
Page 2 Miles Industries Ltd. grants no warranty, implied or stated, for the installation or maintenance of your heater, and assumes no responsibility for any consequential Valor Fireplaces 190–2255 Dollarton Highway damage(s). North Vancouver, BC, Canada V7H 3B1 T 604.984.3496 F 604.984.0246...
Page 3: Table Of Contents
Welcome to Valor ® This appliance has been professionally installed by: Please read this manual BEFORE installing and operating this Dealer Name: ________________________________ appliance. Phone:______________________________________ Fireplace Safety ..........4 Installation ............29 Speciﬁ cations ............. 6 Installing Electrical Wiring ........29 Connecting Gas Supply ..........31...
Page 4: Fireplace Safety
ﬁ replace. Failure to follow these instructions may result in possible ﬁ re hazard and will void the warranty. Replacement manuals are available by contacting the Valor Customer Service at 1-800-468-2567, or by visiting valorﬁ...
Page 5 Fireplace Safety • This gas ﬁ replace and vent assembly must be vented Glass windows directly to the outside and must never be attached to • The glass front assemblies must be in place and sealed a chimney serving a separate solid fuel burning ap- before the unit can be placed into safe operation.
Page 6: Speciﬁ Cations
Specifications Approval & Codes Supply Gas This appliance is certiﬁ ed to ANSI Z21.88-2017/CSA Heater engine 2100PKN is used with natural gas. 2.33-2017 American National Standard / CSA Standard Heater engine 2100PKP is used with propane gas. for Vented Gas Fireplace Heaters for use in Canada The supply pressure must be between the limits and USA, and to CGA 2.17-91 High Altitude Standard in shown in the Ratings section.
Page 7: Kits & Accessories
Kits & Accessories Required Kits Fuel Beds (choose one) 2100BLK Birchwood Log Kit 2100RSS Rock and Shale Set 2100DWK Driftwood Log Kit 2100DGM Decorative Glass Murano Set Liners (choose one) 2100RGP Reﬂ ective Glass Panel 2200FBP Fluted Black Panel 2200LMP Limestone Panel HeatShift Outlets (choose one) LDK3...
Page 8: Dimensions And Location
Dimensions and Location Dimensions 4” x 6-5/8” vent collar HeatShift 5” dia. Electrical Inlet Point outlets (4) Center of vent at wall end 9-1/4” [235 mm] Temporary valve access Gas Line Stub at wall end 1/2” NPT male on this side only Top View 46-3/4”...
Page 9: Installation Planning
Installation Planning Before Installing Caution Only qualified, license, or trained personnel should install this appliance. 1. YOU NEED TO KNOW FROM THE HOMEOWNER: • The thickness and type of wall ﬁ nish around the appliance. • What accessories (if any) will be installed with this unit.
Page 10: Overview - Wood Framing
Installation Planning Overview - Wood Framing Installers can implement an all-wood framing installation for full height installations. Included standoﬀ s on top of WARNING the unit give minimum clearance for combustible framing Ensure weight of wall above is materials from the top of the unit. NOT carried by the appliance.
Page 11: Overview - Steel Framing
Installation Planning Overview - Steel Framing The easiest way to frame a ceiling height installation, the Steel Framing Kit (2100SFK) allows installers to quickly WARNING and easily install a complete framing option purpose-built Ensure weight of wall above is and size for the 2100P. Refer to the Installation Manual NOT carried by the appliance.
Page 12: Overview - Heatshift Canopy
Installation Planning Overview - HeatShift Canopy For installations that do not extend vertically all the way to the ceiling, the HeatShift Canopy kit (2100HSC) allows the installer to install the ﬁ replace WARNING and oﬀ set the HeatShift system to the side, maintaining visual space above Ensure weight of wall above is the ﬁ...
Page 13: Clearances To Combustibles
Installation Planning Clearances to Combustibles WARNING Non-combustible material Ensure weight of wall above is NOT carried by the appliance. must be non-combustible material to 9” 4” clearance from appliance face to combustible wall (studs allowed as shown) Combustible wall surface Fireplace 24”...
Page 14: Wood Framing
Installation Planning Wood Framing WARNING WARNING Ensure weight of wall above is There are restrictions for where drilling and NOT carried by the appliance. screwing may take place. See page 18 for details. HeatShift plenum or duct plates framing required (top, front, or sides).
Page 15: Steel Framing Kit
Installation Planning Steel Framing Kit WARNING WARNING Ensure weight of wall above is There are restrictions for where drilling and NOT carried by the appliance. screwing may take place. See page 18 for details. HeatShift plenum or duct plates framing required (top, Combustible studs (2) front, or rear).
Page 16: Vent Height Considerations
Installation Planning Vent Height Considerations Minimum Vertical Vent Below is the minimum vent height when the elbow is placed directly on the appliance collar*. If calculating the vent height using additional vent lengths, subtract approximately 1-1/2” for each pipe joint. For example, an additional 12” pipe section will add approximately 10-1/2”...
Page 17: Wall Finish
Non-Combustible Cement Board • Always pre-drill screw holes through cement The LX1 ﬁ replace requires a 1/2” [13 mm] thick non- board and use screws with self-milling head. combustible cement board to be used as a wall surface as indicated in “Clearances to Combustibles” on page 13.
Page 18: Screwing And Drilling Restrictions
Installation Planning Wall Finish Screwing and Drilling Restrictions Gas and Controls Side Because of gas, controls, and electrical services behind the ﬁ replace’s walls, there are two areas where you must not drill or place screws. See the diagrams at right for dimensional details of these restricted areas.
Page 19: Venting
Venting Materials Overview Vent Material Framing Vent in Combustible Walls & Ceilings This unit is approved for installation using 4 x 6-5/8-inch When penetrating through combustible walls and co-axial direct vent pipe and accessories as listed in the ceilings, frame a minimum of 10 in x 10 in opening and “Approved Venting Components”...
Page 20: Co-Axial
Venting Co-axial Typical Co-axial Venting Components This appliance is supplied with 4x6-5/8” top vent collar. See “Approved Venting Components” starting on page 53 VERTICAL for a full list of recommended components. TERMINATION STORM Max. 18” if no COLLAR vertical rise in vent HORIZONTAL FLASHING TERMINATION...
Page 21: Venting Chart
Venting Co-axial How to Read the Venting Chart 6. Each 90° elbow installed on the horizontal plane is equivalent to a 3 feet horizontal pipe; therefore, 3 The chart below applies to co-axial roof or wall feet must be subtracted from allowable horizontal termination.
Page 22: Restrictor Location
Venting Restrictor Adjustment Restrictor Location 3. To adjust the restrictor, loosen (but do not remove) the two screws holding the plate in place, and slide it MOST INSTALLATIONS REQUIRE RESTRICTORS for to the desired position. improved ﬂ ame picture and performance. The level of restriction required depends on the vertical rise in the 4.
Page 23: Horizontal Vent Termination Location
Venting Co-axial Termination Horizontal Vent Termination Location Horizontal Vent Termination Location air ow or a safety hazard. Local codes or regulations may require greater clearances. • The vent terminal must be located on an outside wall or through the roof. •...
Page 24: Vertical Vent Termination
Venting Co-axial Termination Vertical Vent Termination Minimum Overhang should not Roof Pitch "H" (feet) extend beyond vent if within 48” of Horizontal Flat to 7/12 termination cap overhang Over 7/12 to 1.5' 8/12 Termination Over 8/12 to 2’ Min. 24” 9/12 (unvented soffit) Over 9/12 to...
Page 25: Co-Linear Venting
Venting Co-linear Venting Co-Linear Vent Installations Co-linear portion of vent system may only be installed Approved co-linear within a solid-fuel burning ﬁ replace and chimney. termination or approved co-linear adapter and The appliance must not be connected to a chimney ﬂ ue approved co-axial serving a separate solid-fuel burning appliance.
Page 26: Appliance Preparation
Appliance Preparation Unpacking the Fireplace Unpacking the Fireplace 3. Hook the window handle to one of the spring loaded window levers. Caution Beware of sharp edges! Wear gloves! Remove packaging from appliance and discard. 4. Pull the window retainer hooks out and up from the Unpack any loose items from around the appliance.
Page 27: Installing Handles
Appliance Preparation Installing Handles Installing Carrying Handles 4. On the other end of the unit, fasten the other handle on with six screws. The ﬁ replace ships with two carrying handles attached to the shipping pallet - they must be properly attached to the ﬁ...
Page 28: Installing Standoﬀ S
Appliance Preparation Installing Standoffs Install Top Standoﬀ s Once all four standoﬀ s are folded up, screw each one down at its remaining connection point. If installing using combustible framing, the included standoﬀ s on top of the unit must be set up. When shipped, the standoﬀ...
Page 29: Installation
Installation Electrical Wiring Installing Electrical Wiring 3. Open the cover and pull out the 3 wires and terminal blocks attached to the receptacle inside the box. This section provides information to install the electric wiring required for use with your ﬁ replace’s lighting and other options.
Page 30 Installation Electrical Wiring Accessing Junction Box After Finishing 6. Connect like wires using supplied terminal blocks. To access the electrical junction box after wall ﬁ nishing is complete and the ﬁ replace is operational, you must remove the bottom plate. Screw the cover plate back onto the ﬁ...
Page 31: Connecting Gas Supply
Installation Gas Supply Connecting Gas Supply Locating Gas Valve The gas supply inlet connection is a 1/2” NPT male Once connected, gas may be isolated within the unit connector located on the wall end of the ﬁ rebox. using its built-in valve. The valve is located as shown below.
Page 32 Installation Gas Supply Pressure Test the Supply Line for Leaks Pressure Test Points The appliance and its individual shut-oﬀ valve must be The minimum supply pressure is given in the Speciﬁ ca- disconnected from the gas supply piping system during tions section of this manual, see page 6.
Page 33: Installing Wall Switch Kit
Installation Wall Switch Kit Installing Wall Switch Kit IMPORTANT: The connection can only be done one way. A remote battery wall switch kit is provided with this appliance. It is connected to the receiver in the ﬁ replace. The receiver is located under the bottom plate. 1.
Page 34 Installation Wall Switch Kit 9. Plug the signal wire into the switch plate. 14. Position the battery holder to the rear face and secure together with a cable tie. Note that clearance is required for power wire connection. 10. Mount the switch plate to the junction box with 2 screws provided.
Page 35: Wifi Module (Optional)
Installation WiFi Module (Optional) WiFi Module (Optional) Physical Installation If ordered, the WiFi module (part number GV60WIFI) will The WiFi module must be wired into a compatible require synchonization and setup to allow the ﬁ replace receiver, complete with SI port as shown below. to operate on the homeowner’s network.
Page 36: Liners
Installation Liners Installing a Ceramic Liner 4. Slide the retaining bracket against the liner and tighten the screw. The ceramic Limestone (2200LMP) and Fluted Black (2200FBP) liner kits are both installed the same way. 1. Loosen (but do not remove) the screw next to the panel retaining bracket in the roof of the ﬁ...
Page 37: Installing A Glass Liner
Installation Liners Installing a Glass Liner 4. Fold the bottom clip along its perforation into a right angle, as shown. The 2100RGP Reﬂ ective Glass liner is installed diﬀ erently than the ceramic liners. 1. Loosen (but do not remove) the screw next to the panel retaining bracket in the roof of the ﬁ...
Page 38: Fuel Beds
Installation Fuel Beds Installing Birch Log Kit 2100BLK Material required • Birch Log Kit, which contains: • 7 logs • 2 supports • 1 bag of embers (not pictured) • 1 bag of splinters (not pictured) • Gloves, if desired 2.
Page 39 Installation Fuel Beds 5. Place log L6 across log L4 as shown. 9. Place embers by hand onto the burner and media tray (avoid pouring as this can deposit ﬁ ne dust in the burner ports). You may not need to use all the em- bers supplied.
Page 40: Installing Driftwood Kit 2100Dwk
Installation Fuel Beds Installing Driftwood Kit 2100DWK 1. Place the vermiculite onto the burner by hand (avoid pouring as this can deposit ﬁ ne dust in the burner Material required ports). Be careful not to overﬁ ll and block any burner •...
Page 41 Installation Fuel Beds 4. Place log 3720 into the two pinholes behind the pilot 7. Place log 2939 onto the pin on log 3720. Leave the light. Note this leaves a pin pointing straight up. other end of log 2939 across the media tray. 8.
Page 42: Installing Rock And Shale Set 2100Rss
Installation Fuel Beds Installing Rock and Shale Set 2100RSS 3. Ensure the pilot light safe zone is not blocked by embers. This is important to ensure proper ignition. Material required • Rock and Shale Set, which contains: • 4 logs •...
Page 43 Installation Fuel Beds 7. Repeat on the right hand side of the ﬁ replace. 8. The completed arrangement will look like the one below. • Note some minor adjustments may be needed to improve ﬂ ame picture.
Page 44: Installing Glass Murano Set 2100Dgm
Installation Fuel Beds Installing Glass Murano Set 2100DGM 3. Place ﬁ reglass onto the burner by hand. You may not need to use the entire bag. Material required • Decorative Glass Murano Set, which contains: • 2 Murano glass covers •...
Page 45: Remote Control Set-Up
Installation Remote Control Set-Up Remote Control - Radio Frequency 918.0 MHz for USA and Canada. This device complies with Part 15 of the FCC Rules and with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference...
Page 46: Installing Remote Control Handset Wall Holder
Installation Remote Control Set-Up Installing Remote Control Handset Wall Holder The remote control kit for this ﬁ replace comes complete with a wall-mounted holder. This holder is not required in all installations but is provided as an optional feature for those customers who wish to mount the remote handset to the wall.
Page 47: Replacing Light Bulbs
65). If any of the bulbs are out, replace them using the following steps. Required Bulbs The light bulbs in the LX1 are 120V, 20W bi-pin (JC) halogen bulbs GY6.35. A total of 4 are installed in the unit. Remove Barriers and Windows Changing the light bulbs requires access to the inner ﬁ...
Page 48: Re-Installing Windows
7. Repeat steps 1 to 6 for the other side window. conditions. 8. Pull the top of each window to ensure it the spring mechanisms are working well and pull the window Damage caused by incorrect window back into position. installation is not covered by the Valor Warranty.
Page 49: Checking Operation And Aeration
Installation Checking Operation and Aeration Checking Operation Turn the ﬁ replace ﬂ ame up and down using the remote control to conﬁ rm that the full range of inputs is achieved—see the remote control operation instructions Set air shutter in “Appendix B - Remote Control Operation” on page using a screwdriver as a lever against Close...
Page 50: Installing Plates And Barrier Screens
Installation Installing Plates and Barrier Screens Installing Plates Install Barrier Screens For safety, install all plates (top and bottom) as supplied For safety, install all barrier screens as supplied with the with the ﬁ replace if they have been removed. ﬁ...
Page 51: Wiring Diagram
Wiring Diagram GV60 Wiring Diagram MAN Knob Battery Holder Main Valve Knob AC Power Lights RBWSK Combination Control Valve black Interruptor Block V-Module Connector Thermocouple yellow Wifi Module Antenna (optional) Receiver Battery Holder RESET Button...
Page 52: Approved Venting Components
Approved Venting Components Approved Direct Vent Suppliers for Valor Model 2100 Venting Parts Code / availability by Manufacturer Venting Parts Description Standard Co-axial 46DVA-HC 4DT-HC TM-4HT — — 4DHC round 658DVK2 940160 Deluxe Co-axial — — TM-4RHT — — 4DHCS square —...
Page 53 658TG Notes: 1. All listed above co-axial pipes and ﬁ ttings require Valor 817VAK Adapter Kit to ﬁ t Valor’s smooth collars (Valor adapter 4DSC-V by American Metal Products may also be used). 2. Follow instructions supplied with each manufacturer’s components.
Page 54: Commonwealth Of Massachusetts
Commonwealth of Massachusetts State of Massachusetts Carbon Monoxide 2. APPROVED CARBON MONOXIDE DETECTORS. Each carbon monoxide detector as required in accordance Detector/Vent Terminal Signage with the above provisions shall comply with NFPA 720 Requirements and be ANSI/UL 2034 listed and IAS certiﬁ ed. For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential...
Page 55 Commonwealth of Massachusetts (c) MANUFACTURER REQUIREMENTS - GAS EQUIPMENT VENTING SYSTEM PROVIDED. When the manufacturer of Product Approved side wall horizontally vented gas equipment provides a venting system design or venting system components with the equipment, the instructions provided by the manufacturer for installation of the equipment and the venting system shall include: 1.
Page 56: Spare Parts
Spare Parts Part Part Description Description Number Number Barrier screen front/rear (2) 4006979 Gas oriﬁ ce DMS #42 - natural gas 4007000-42 Barrier screen end 4006865 Gas oriﬁ ce DMS #53 - propane 4007000-53 Window assembly front/rear (2) 4006727 Pilot gaskets (2) 4000715 Window assembly end 4006469...
Page 57 Spare Parts Part Part Description Description Number Number Reﬂ ective glass panel liner 2100RGP Driftwood log kit 2100DWK Limestone liner 2200LMP Driftwood log 2965 4002965 Fluted black liner 2200FBP Driftwood log 2967 4002967 Decorative glass Murano set 2100DGM Driftwood log 3720 4003720 Murano glass rear 4006858...
Page 58 Spare Parts 6 (4) 3 (2) 5 (4) 1 (2) 29-35 6 (4) 20 (2) 37 (2) 37 (2) 41 (2) 41 (2) 42 (2) 42 (2) 64 (4)
Page 59 Spare Parts 2100DGM 2200LMP 2100RGP 2200FBP 2100BLK 85 (2) 2965 2100DWK 2966 2967 3720 2939 95-100 2100RSS 105-110...
Page 60: Appendix A - Lighting Instructions Plate
Appendix A - Lighting Instructions Plate FOR YOUR SAFETY, READ BEFORE LIGHTING WARNING : If you do not follow these instructions exactly causing property damage, personal injury or loss of life. A. This appliance has a pilot which must be lighted by hand or by remote control. Follow these instructions exactly. To save gas, turn the pilot off when not using the appliance for a prolonged period of time.
Page 61: Appendix B - Remote Control Operation
Appendix B - Remote Control Operation Initial Pairing Before the remote control can be used with the ﬁ replace, it must be paired. See “Remove the Windows” on page Main Display Child Proof Time Signal Indicator Thermostatic Mode Battery Status Fan (if included) (not applicable) Countdown Timer...
Page 62 Appendix B - Remote Control Operation Designated Low Fire and High Fire To deactivate functions: To go to low ﬁ re, double-click . “LO” 1. Install batteries. All icons are displayed and ﬂ ashing. is displayed. 2. While the icons are ﬂ ashing, press the relevant func- tion button and hold for 10 seconds.
Page 63 Appendix B - Remote Control Operation Child Proof Light/Dimmer Operation Your handset can be set to lock out all commands to the ﬁ replace, except OFF. Press is displayed. Light is on at preset level. To turn Child Proof ON: 1.
Page 64 Appendix B - Remote Control Operation Modes of Operation Thermostatic Mode Thermostatic Mode The room temperature is measured and Press . is displayed. Preset compared to the set temperature. The temperature displays brieﬂ y, followed ﬂ ame height is automatically adjusted by the room temperature.
Page 65 Appendix B - Remote Control Operation Temperature Setting: Off Time Setting (PROGRAM 1) , 1, OFF 1. Press and hold until ﬂ ashes. are displayed. ALL is ON and set temperature (set in Ther- displayed brieﬂ y. Hour ﬂ ashes. mostatic Mode) is displayed.
Page 66 Appendix B - Remote Control Operation Low Battery Indication Low Battery Receiver With low battery power in the battery holder, the system shuts oﬀ the ﬁ re completely. (This will not CAUTION: Do not use a screwdriver or other happen if the power is completely interrupted.) metallic object to remove the batteries from the battery holder or the handset.
Page 67 Appendix B - Remote Control Operation Error Codes In the event of an error condition with the handset or ﬁ replace, the handset will display an error code. Failure Message on Duration of Symptom Possible Cause Code Handset Display 4 sec •...
Page 68: Appendix C - Wall Switch Operation
Appendix C - Wall Switch Operation Using the Wall Switch Turning Appliance ON and OFF The Wall Switch can be used to control the ﬁ replace. You Press ON-OFF button once to light can turn the pilot on or oﬀ and you can increase or pilot.
Page 69: Appendix D - Heatshift
Appendix D - HeatShift Planning and Installation: LX1 with HeatShift ® For use with 2100K Valor Heaters ONLY Application WARNING The HeatShift convection duct kit redistributes the ® warm air ﬂ ow away from the ﬁ replace opening to DO NOT cover or place objects in front of a more desirable location using natural convection or on top of air outlet(s).
Page 70 Appendix D - HeatShift 2100HSC Kit Contents 2100HSC Takeoﬀ collars not required. Qty (2) 2x4 cut to planned height required (not included)
Page 71 Appendix D - HeatShift LDK Kits Contents LDK4 38” x 2” 39-5/8” (1007 mm) 3-5/8” (4) 5” Ø take-off (92 mm) collars included LDK5 (supplied separately) 38” frame, white LDK3 15-3/4” (400 mm) 2 - 14” x 6” 7-3/4” (197 mm) (4) 5”...
Page 72 Appendix D - HeatShift Suggested Conﬁ gurations Not to scale LX1 Series with LDK Kits WARNING Front or rear wall outlet using LDK4 The plenum duct kits are approved for horizontal discharge ONLY. The termination duct plates are approved for vertical upward discharge ONLY. DO NOT install plenum or termination plates in ﬂ...
Page 73 Appendix D - HeatShift Overview - 2100HSC kit Coaxial vent can run vertically through ceiling Ceiling Min 2-1/2” [64 mm] clearance to ceiling Flexible or rigid 5” Ø, UL-181, Class 1 Air Duct (2). Use LDK 6 kit or equivalent. Installer may separate top duct from middle duct...
Page 74 Appendix D - HeatShift Overview - LDK3 and LDK4 kits Note: Venting must be offset Flexible or rigid around 36” 5” Ø, UL-181, Min. 1” plenum Class 1 Air clearance to Duct (4). Use LDK 6 kit or combustibles around pipes. equivalent.
Page 75 Appendix D - HeatShift Overview - LDK7 kit Note - Discharge opening must be located in the same room as fireplace when using LDK7. Ceiling Top of Wall Finish Min 2-1/2” opening required at ceiling Flexible or rigid 5” Ø, UL-181, Class 1 Air Duct (4).
Page 76 Appendix D - HeatShift Max. Allowable LDK 3 or LDK 4 Vertical Rise Horizontal Ceiling Offset 30” 24” Min. 2-1/2” 8” clearance 36” 36” to ceiling 42” 48” Min. bend 48” 60” radius 5” 54” 72” Support horizontal Min. 1” Vertical Rise 60”...
Page 77 Appendix D - HeatShift Plenum Dimensions LDK 4 3-5/8” 11-1/2” 7-7/8” Top View 1/2” wallboard 38” LDK 4 11-1/2” mounting 1/2” bracket and standoffs 1-1/2” standoff 3” 2” 8” 5” dia. mounting collars (4) bracket and 1/2” standoff 1/2” standoff 6”...
Page 78 Appendix D - HeatShift LDK7 Plates Dimensions Perimeter of plates may be trimmed to suit installation Warning Label 16” Stand-offs Stand-offs Top View (fold down for shipping) 5” dia. collars (4) 4-1/2” 7” 4-1/2” 9-3/4” 9-3/4” 19-1/2” Front View Right Side View...
Page 79 LDK 4 Framing and Clearances Rough Frame Opening LDK 4 = 39” Use steel stud LDK 3 = 15” See detail for LX1 appliances Rough Frame 2 x 4 steel stud Opening Min. 1/2” clearance to LDK 4 = 4”...
Page 80 Appendix D - HeatShift Framing and Clearances Min. 2-1/2” clearance to ceiling 1-1/2” min. clearance to combustibles (top) Ceiling 1/2” min. 1/2” clearance to combustibles 5” rear & sides 1 x 4 on edge to 2” min. clearance support plenum. to combustibles Maintain 1”...
Page 81 Wall Valance Discharge Opening using LDK7—Duct Termination Plates Continuous ceiling Minimum length required within cavity of opening, front and sides Plate stand-off LX1 - 2100 = 40“ See clearances 2-1/2” min. to combustibles Wall finish required Ceiling next page to form plenum 14”...
Page 82 Appendix D - HeatShift LDK7 Clearances to Combustibles Perimeter of plates may be trimmed to 4” suit installation 4” Stand-off Stand-off 16” Non-combustible zone above plates Top View 4” 4” 4” 4” Stand-offs Combustible framing allowed below plates 5” dia. pipes - maintain 1”...
Page 83 Appendix D - HeatShift 4. Install the plenum(s) into the rough frame opening maintaining minimum clearances to combustibles WARNING as previously listed. Fix the plenum to the framing A l l F O U R ( 4 ) t a k e o f f s M U S T B E using nails or screws through the top mounting C O N N E C T E D T O P L E N U M ( S ) .
Page 84 Appendix D - HeatShift 5. Attach one section of UL-181, Class 1 approved air duct to each of the collars and secure it with gear WARNING clamps provided. DO NOT SPLICE DUCTS! A l l F O U R ( 4 ) t a k e o f f s M U S T B E 6.
