Valor LX2 CORNER Installation Manual

Direct vent zero clearance gas fireplace, natural/propane gas
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Installation Manual
LX2
Installer: Leave this manual with the appliance.
Consumer: Retain this manual for future reference.
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings
exactly could result in serious
injury, death, or property damage.
Do not store or use gasoline or other
fl ammable vapors and liquids in the
vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
▪
DANGER
4007769-07
©2021, Miles Industries Ltd.
Direct Vent Zero Clearance
Gas Fireplace
natural gas
propane gas 2200LKP / 2200RKP
CORNER
▪
▪
▪
▪
Installation and service must be
performed by a qualifi ed installer, service
agency or the gas supplier.
Hot glass
will cause burns.
Do not touch glass
until cooled.
Never allow children
to touch glass.
2200LKN / 2200RKN
Installer: Place model/serial number here.
Do not touch any electrical switch; do
not use any phone in your building.
Leave the building immediately.
Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
If you cannot reach your gas supplier,
call the fi re department.
A barrier designed to reduce
the risk of burns from the hot
viewing glass is provided with this
appliance and must be installed for
the protection of children and
other at-risk individuals.
