Initial setup and connectivity
Setting
Port Mirroring
Profile
Service
SSH Status
SSH Fingerprint
2. Scroll to the option that you want to change and press Change or touch OK to toggle the
selected setting from the available options. The deskphone displays the softkeys Save,
Change, and Cancel.
3. If you have made any changes to the Debug Mode option, then you must press or touch
the Save option. This action resets the phone and saves the changes to the debug screen.
Note:
When SSH is manually enabled, the SSH port will only be opened for one SSH
connection. When that connection is terminated, the port will be closed, and it must be
reopened (SSH must be re-enabled) from the Craft Debug procedure if another
connection is to be established.

Changing Ethernet interface control

About this task
Use the following procedure to set or change the interface control value.
Procedure
1. When you select INT from the Craft Procedures screen, the phone displays the following
options with a prompt to use the Right and Left navigation arrows to select a setting:
Ethernet
PC Ethernet
The options that are displayed are the text strings associated with the current PHY1STAT
on the Ethernet line and the current PHY2STAT system value on the PC Ethernet line.
• Auto when PHY1STAT = 1
• 10 Mbps half when PHY1STAT = 2
May 2018
Options available
Note:
The Phone Report option is available only if backup and restore is
enabled.
On/Off
H.323 signaling over TLS to On/Off
Service mode control/Service mode record to On/Off
Enabled/Disabled
Note:
The SSH Status option displays an Active status if an SSH connection is
already established.
Installing and Administering Avaya J169/J179 IP Phone H.323
Comments on this document? infodev@avaya.com
Choice Selector
