Advantech-DLoG DLT-V83 Series Operating Instructions Manual page 99

Channel List
Select all 2.4Ghz
channels
Select all 5Ghz
channels
Select all channels
Band
CCX Control
CCX / CCKM
DLT-V83 Operating Instructions V2.00
This option can be used for simultaneous pre-selection of all
2.4 GHZ channels 1 to 13 supported by the WLAN driver.
Modifications to individual channels can be carried out at any time
by clicking the checkboxes for each channel.
NOTICE: Country-specific channel settings / residual restrictions on
the use of special channels should be set according to the legal
guidelines and must be observed!
This option can be used for simultaneous pre-selection of all 5 GHZ
channels 36 to 140 supported by the WLAN driver.
Modifications to individual channels can be carried out at any time
by clicking the checkboxes for each channel.
NOTICE: Country-specific channel settings / residual restrictions on
the use of special channels should be set according to the legal
guidelines and must be observed!
Used to select or de-select the complete channel list 2.4/5 GHZ (to
simplify channel selection).
The following selection options are available:
2.4 GHz
5 GHz
Dual band (2.4 GHz and 5 GHz)
The corresponding settings mean that only channels occurring in
the frequency band are displayed for selection and de-selection.
The CCX specification (Cisco
series of functional extensions to the IEEE 802.11 WLAN
standard to support rapid roaming (CCKM): with improved
security, reliability and diagnostic performance.
The CCX specification is a brand from Cisco
license agreement to be able to equip mobile devices with this
technology.
Currently the CCX versions 4 (CCXv4) and 5 (CCXv5) are
supported.
®
Compatible eXtensions) contains a
®
and requires a
WLAN configuration
99 / 157
