Power supply, power consumption, power supply unit fuses
Power supply, power consumption
AC power supply unit, internal, Type: AC-4
Rated voltage
Voltage range
Input frequency
Bridgeable power failures
Maximum output power
Rated current
Power consumption:
DLT-V8315 with
Intel
Power consumption:
DLT-V8315 with Intel
CPU and Intel
Power supply unit fuses
Power supply unit
AC- 4
The symbol for the fuse is FA.
You will find the exact position on the sticker located on the connection plate of the DLT-V83.
DLT-V83 Operating Instructions V2.00
®
Atom™ D525 CPU
®
Core™ i5-4300U
® ®
Celeron 2980U CPU
Fuse type
5 x 20 mm
T 1.0 A H / 250
V
Electrically isolated
100 to 240 VAC
85 to 264 VAC
50/60 Hz
Typically 22 ms at Uin = 115 VAC
60 W
1 A max.
Typically 30 W
Typically 40 W
Example
Bussman S505-1-R
Littelfuse 0215 001.
Schurter 0001.2504
Siba 179200.1
or similar produced by other manufacturers
Technical data of the device
