Technical data of the device
Sunlight readable touchscreen version (optional)
Sunlight readable touchscreen
Type
Construction
Hardness of surface
Mechanical resistance
Chemical resistance to
industrial chemicals
5.1.7.

Projected-capacitive touchscreen (PCT)

Some DLT-V83 device models are available optionally with a PCT, for example:
− DLT-V8310 XGA with 9 front keys
− DLT-V8310 SVGA with 9 front keys
− DLT-V8312 with 9 front keys
− DLT-V8315 with 9 front keys
PCT touchscreen
Type
Construction
Hardness of surface
Mechanical properties
Chemical resistance
16 / 157
5-wire analog resistive touchscreen
Film-Glass (FG), chemically toughened glass
JIS-K-5400: 1 H at 750 g
Shock resistance IK08 according to IEC 62262
Tapping: > 10 million times with rubber test pen
Swiping: > 100,000 times with polydactyl pen
Hydrogen peroxide, iso alcohol 50 5, iso alcohol 70%, mineral
spirits, gasoline, motor oil, diesel fuel, transmission fluid, brake
fluid, antifreeze, hydraulic oil, bleach, ethanol, turpentine, acetone,
"diethylene glycol monoethyl ether acetate", toluene, petroleum
ether, hydrochloric acid, glycol ether acetate, MEK, heptane,
sodium hydroxide
Projected-capacitive touchscreen
Glass film
Hardness JIS-K-5400: > 10 H at 750 g
Shock resistance IK08 according to IEC 62262
Chemical AR coated glass with gloss value 60 according to
ISO 2813, 7668; ASTM D 523, D 2457; DIN 67539
Thermally pre-stressed, acid-etched planibel float glass
Resistant to chemicals.
Not resistant to strong acids, gasoline and diesel.
DLT-V83 Operating Instructions V2.00
