Phones Out 1
• 1 x 6.3 mm TRS jack, mono / stereo
• Output level: max. +18 dBu
• SNR: -115 dB RMS (20 Hz - 20 kHz) / -118 dB(A)
• THD+N @ 0 dBFS: -105 dB @ 600 Ω
Phones Out 2
• 1 x 3.5 mm TRS jack, mono / stereo
• Output level: max. +12 dBu
• SNR: -115 dB RMS (20 Hz - 20 kHz) / -118 dB(A)
• THD+N @ 0 dBFS: -105 dB @ 600 Ω
USB
• 1 x USB socket (Type B)
• for firmware updates
GPIO
• 2 x GPI (MOSFET switch),
• 2 x GPO (MOSFET switch)
• 2 x USB 2.0 for legacy control of ANDIAMO devices
MADI Port SC optical
• 1 x SC socket FDDI (input / output)
• ISO/IEC 9314-3
• Wave length 1310 nm
• Multi-Mode 62.5/125 or 50/125
MADI Port BNC coaxial
• 2 x BNC socket (input / output)
• Impedance: 75 Ω
• 0.3 V up to 0.6 V (peak to peak)
MADI Port SFP
• 1 x SFP (empty cage without module)
MADI Format (I/O)
• 48k Frame, 96k Frame
• 56 channel, 64 channel
